2.4.11 LCD backlight brightness adjustment (JVR1)
2.4.12 Low pin count connector (JLPC1)
Signal
BRIGHT
CLK_LPC
LPC_FRAME#
PLT_RST#
Data Modul AG - www.data-modul.com
PIN
+5V
1
2
GND
3
Variation Resistor
(Recommended: 4.7KΩ,
Signal
PIN PIN
GND
14
13
GND
12
11
GND
10
9
8
7
6
5
4
3
+3.3V
2
1
ECM-QM57 User's Manual 29
User's Manual
>1/16W)
Signal
+5VSB
+5V
INT_SERIRQ
LPC_AD3
LPC_AD2
LPC_AD1
LPC_AD0
