ECM-QM57

2.4.5 Battery connector (BBAT1)

2.4.6 CFAST LED connector (BLED1/ BLED2)

26
ECM-QM57 User's Manual
BLED2
BLED1
Data Modul AG - www.data-modul.com
Signal
PIN
GND
2
VBAT
1
Signal
PIN
GND
2
BLED1/ BLED2
1
