ECM-QM57

2.4.9 Audio connector (JAUDIO1)

2.4.10 +12V power Connector (JBKL1)
28
ECM-QM57 User's Manual
Data Modul AG - www.data-modul.com
Signal
PIN PIN
GND
12
11
LIN1_JD
10
9
MIC1_L
8
7
LIN1_L
6
5
GND
4
3
FRONT_L
2
1
Signal
+12V
GND
Signal
MIC1_JD
FRONT_JD
MIC1_R
LIN1_R
GND
FRONT_R
PIN
1
2
