1.5 System Specifications

System
CPU
BIOS
System Chipset
I/O Chip
System Memory
SSD
Watchdog Timer Reset
H/W Status Monitor
Expansion
I/O
MIO
USB
DIO
Display
Chipset
Resolution
Multiple Display
LVDS
Audio
AC97 Codec
Audio Interface
12 ECM-QM57 User's Manual
Onboard Intel® Core™ i7-620LE/ 620UE Processor
AMI 64Mbit SPI BIOS
Intel® QM57
Winbond W83627DHG-P
One 204-pin DDR3 SODIMM Socket Supports Up to 4GB DDR3 800/ 1066
SDRAM
One CompactFlash Type I/II Socket
1~255sec./min. and 1sec. or 1min./step
Monitoring System Temperature, Voltage. Auto Trotting Control When CPU
Overheats
1 x PCIe Mini Card Slot (From The Daughter Board )
2 x Serial ATA Ports, 1 x RS-232, 1 x RS-232/ 422/ 485, LPC, 2 x SATA
5 x USB 2.0
8-bit GPI, 8-bit GPO
Intel® QM57
CRT Mode: 2048 x 1536 @ 75Hz
LCD/ Simultaneous Mode: 1600 x 1200 @ 75 Hz
CRT + LVDS, HDMI + LVDS, CRT + HDMI
Dual-channel 18/ 24-bit LVDS
Realtek ALC888 Supports 5.1-CH Audio
Mic-in, Line-in, Line-out
