- Page 1 ACS-B1086 User’s Guide ACS-B1086 Celeron M 1.5G ,OnBoard 512MB DDR2 with DDR2 SO-DIMM, built in Six Giga-LAN, nine COM port Edition: 1.02 Book Number: ACS-B1086-08.08.12...
- Page 2 Trademarks ACS-B1086 is registered trademarks X-Fire Acrosser, IBM PC is a registered trademark of International Business Machines Corporation. Pentium is a registered trademark of Intel Technologies, Inc. Award is registered trademarks of Award Software International, Inc.
-
Page 3: Table Of Contents
Contents ..............3 Introduction ............. 5 Specifications: ............... 5 What You Have..............7 Installation .............. 8 ACS-B1086’s Layout ............. 8 Power Button Setting ............. 9 CMOS Reset................9 Jumper description ..............9 Connection............10 Ultra ATA33 IDE Disk Drive Connector(IDE1)..... 10 Keyboard / Mouse Connector(MSKB1) ...... - Page 4 ACS-B1086 User’s Guide Serial ATA(SATA1 / 2) ............14 3.10 Serial Ports(COM1~COM8) ..........14 3.11 Connector port(IDE4 / 5)............. 15 3.12 CPU STEPING OPTION(SW1,SW2)........17 Award BIOS Setup..........18 Introduction ................ 18 Starting Setup ..............18 Using Setup................ 19 Main Menu ................. 20 Advanced BIOS Features ..........
-
Page 5: Introduction
ACS-B1086 User’s Guide Introduction 1.1 Specifications: CPU : Intel Celeron M 1.50 GHz FSB400 1MB-L2 Cache CPU. Chipset : GMCH 910GMLE and ICH6M 82801FBM RAM memory : OnBoard 512MB DDR2 with DDR2 SO-DIMM Socket support to 1GB/533MHz. Display Controller: Intel® Graphics Media Accelerator 900 (Intel® GMA 900) Ultra DMA 33 IDE Interface : One 44pin Enhance IDE channel. - Page 6 ACS-B1086 User’s Guide Intel LAN Controller Six ports Giga LAN, four Intel® 82574L,two 82541PI Gigabit Ethernet Controller provides a standard IEEE 802.3 Ethernet interface for 1000BASE-T, 100BASE-TX, and 10BASE-T applications (802.3, 802.3u, and 802.3ab, respectively). Power Consumption : +12V / 3.5A Operating Temperature : 0 °...
-
Page 7: What You Have
ACS-B1086 User’s Guide 1.2 What You Have In addition to this User's Manual, the ACS-B1086 package includes the following items: ACS-B1086 board User Manual Drive CD ACS-B1086... -
Page 8: Installation
ACS-B1086 User’s Guide Installation This chapter describes how to install the ACS-B1086. At first, the layout of ACS-B1086 is shown, and the unpacking information that you should be careful is described. The jumpers and switches setting for the ACS-B1086’s configuration 2.1 ACS-B1086’s Layout... -
Page 9: Power Button Setting
ACS-B1086 User’s Guide 2.2 Power Button Setting • ATX1 : Power Connector DESCRIPTION +12V +12v • J1 : Power, Reset, Speak button Header DESCRIPTION DESCRIPTION SPK- +3.3V PANSWIN HDD LED 1-2 : speak out. 5-6 : power on button. 7-8 : hard disk LED. -
Page 10: Connection
ACS-B1086 User’s Guide Connection This chapter describes how to connect peripherals, switches and indicators to the ACS-B1086 board. 3.1 Ultra ATA33 IDE Disk Drive Connector(IDE1) You can attach one IDE( Integrated Device Electronics) hard disk drives to the ACS-B1086 IDE controller. -
Page 11: Keyboard / Mouse Connector(Mskb1)
• KBMS1 : Keyboard Mouse PS2 pin header Description MS_DATA KB_DATA MS_CLK KB_CLK 3.3 USB Port Connector(USB3 / 4) The ACS-B1086 provides six USB port, four pin header, two on the connector IDE3 . • USB3/4 : USB pin header DESCRIPTION DESCRIPTION USB- USB-... -
Page 12: Vga Connector(Vga1)
PIN NO. DESCRIPTION MDI0+ MDI0- MDI1+ MDI1- MDI2+ MDI2- MDI3+ MDI3- 3.5 VGA Connector(VGA1) The ACS-B1086 has a built-in 10-pin VGA pin header accepting the CRT monitor • VGA1 : 10-pin pin header DESCRIPTION DESCRIPTION GREEN BLUE V-SYNC DDCCLK H-SYNC DDCDATA 3.6 Compact Flash Storage Card Socket(CN1) -
Page 13: Ddr2 Sodimm Socket (Ddr2Sodimm1)
ACS-B1086 User’s Guide PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND CARD DETECT1 CS1# CS3# GROUND IOR# IOW# PULL HIGH IRQ15 MASTER/SLAVE RESET# IORDY PULL HIGH ACTIVE# PDIAG# CARD DETECT2 GROUND 3.7 DDR2 SODIMM Socket (DDR2SODIMM1) There are one 200-pin DDR2 SDRAM DIMM slots to accept 1.8V non_buffered DDR2 SDRAM. -
Page 14: 9-Bit Gpio(Cn6)
ACS-B1086 User’s Guide 3.8 9-Bit GPIO(CN6) The ACS-B1086 includes an on-board 9-bit GPIO pin header. • CN6: 9-Bit GPIO pin header DESCRIPTION DESCRIPTION GPIO10 GPIO11 GPIO12 GPIO13 GPIO14 GPIO15 GPIO16 GPIO17 GPIO20 3.9 Serial ATA(SATA1 / 2) • SATA1 /2 : Serial ATA port DESCRIPTION 3.10 Serial Ports(COM1~COM8) -
Page 15: Connector Port(Ide4 / 5)
ACS-B1086 User’s Guide • J4~J11 : RS-232/RS-422/RS-485 setting pin header DESCRIPTION JUMPER SETTING RS-232 1-3, 2-4, 7-9, 8-10, 15-17 RS-485 3-5, 4-6, 13-15, 18-20(120Ohm) #1 RS-422 3-5, 4-6, 9-11, 10-12, 14-16 Note: #1.RS-485 can selection terminal resister. 18-20 = 120 Ohm, 19-20 = 300 Ohm. - Page 16 ACS-B1086 User’s Guide IDE4 PIN DESCRIPTION IDE3 PIN DESCRIPTION HDD_LED DCD_CONSOLE LAN1_ACT_LED DSR_CONSOLE LAN1_SPD_LED RX_CONSOLE LAN2_ACT_LED RTS_CONSOLE LAN2_SPD_LED TX_CONSOLE LAN3_ACT_LED CTS_CONSOLE LAN3_LINK_LED DTR_CONSOLE LAN4_ACT_LED RI_CONSOLE LAN4_LINK_LED LAN5_ACT_LED LAN5_LINK_LED LAN6_ACT_LED LAN6_LINK_LED LAN2_LINK_LED USB_5V LAN1_LINK_LED USB0- COM1_RX_LED USB0+ COM1_TX_LED USB1- COM2_RX_LED USB1+...
-
Page 17: Cpu Steping Option(Sw1,Sw2)
ACS-B1086 User’s Guide 3.12 CPU STEPING OPTION(SW1,SW2) • SW1,SW2 : CPU steping switch BANIAS, DOTHAN A DOTHAN B BANIAS,DOTHAN A DOTHAN B FBS 400 FSB 533 ACS-B1086... -
Page 18: Award Bios Setup
ACS-B1086 User’s Guide Award BIOS Setup 4.1 Introduction This chapter discusses the Setup program built into the BIOS. Setup program allows users to configure the system. This configuration is then stored in battery-backed CMOS RAM so that it retains the Setup information while the power is off. -
Page 19: Using Setup
ACS-B1086 User’s Guide 4.3 Using Setup In general, you can use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more details about how to navigate in the Setup program using the keyboard. -
Page 20: Main Menu
ACS-B1086 User’s Guide 4.4 Main Menu The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn>... - Page 21 ACS-B1086 User’s Guide Base Memory Displays the amount of conventional memory detected during boot up Extended Memory Displays the amount of extended memory detected during boot up Total Memory Displays total memory available in the system Table 1 Main Menu Selections IDE Adapters The IDE adapters control the hard disk drive.
-
Page 22: Advanced Bios Features
ACS-B1086 User’s Guide menu. IDE Primary Master None Selecting ‘manual’ lets you Auto set the remaining fields on Manual this screen. Selects the type of fixed disk. "User Type" will let you select the number cylinders, heads, etc. Note: PRECOMP=65535... -
Page 23: Power
ACS-B1086 User’s Guide Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power up the computer. If it is set to Enable, BIOS will shorten or skip some check items during POST. Enabled... - Page 24 ACS-B1086 User’s Guide ACPI Suspend Type This item allows you to Choose Suspend Type for ACPI function. The Choice: S1(Pos), S3(STR), S1 & S3. Power-Supply Type This item allows you to choose the Type of Power Supply in use. The Choice: AT, ATX.
-
Page 25: Pnp/Pci Configuration Setup
ACS-B1086 User’s Guide 4.7 PnP/PCI Configuration Setup Figure 4 PnP/PCI menu Resource controlled by The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as Windows®95. -
Page 26: Peripheral
ACS-B1086 User’s Guide 4.8 Peripheral Figure 6 Peripheral menu Onboard Serial Port 1 Select an address and corresponding interrupt for the first and second serial ports. The choice: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, Disabled, Auto UART Mode Select Select the Function Mode for UART. -
Page 27: Pc Health
ACS-B1086 User’s Guide support built in, the support will be automatically turn on when high speed device were attached. The Choice: Enabled, Disabled. 4.9 PC Health Figure 7 H/W Monitor menu 4.10 Boot Figure 8 Boot menu ACS-B1086... - Page 28 ACS-B1086 User’s Guide First/Second/Third/Other Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. The Choice: Floppy ………. [ ] LS120 ………. [ ] Hard Disk …. [ ] CDROM … …….[ ] ZIP100 ……….
-
Page 29: Exit Selecting
ACS-B1086 User’s Guide 4.11 Exit Selecting Save & Exit Setup Load Optimized Defaults Exit Without Saving Load Fail-Save Default Figure 9 Exit menu Save & Exit Setup Pressing <Enter> on this item asks for confirmation: Save to CMOS and EXIT (Y/N)? Y Pressing “Y”... - Page 30 ACS-B1086 User’s Guide Use this menu to load the BIOS default values that are factory settings for optimal performance system operations. While Award has designed the custom BIOS to maximize performance, the factory has the right to change these defaults to meet their needs.
-
Page 31: Appendix A. Watchdog Timer
ACS-B1086 User’s Guide Appendix A. Watchdog Timer The WDT(Watch Dog Timer)is used to generate a variety of output signals after a user programmable cont. The WDT is suitable for use in the prevention of system lock-up, such as when software becomes trapped in a deadlock. Under these sort of circumstances, the timer will count to zero and the selected outputs will be driven. -
Page 32: Appendix B: Digital I/O
