Victoria Arduino ADONIS 3 gruoups Manual page 51

• To access the economiser, remove the cup warmer
section on the left by loosening the two screws "D"
as illustrated in the following figure.
D
• Turn the adjustment knob ANTICLOCKWISE /
CLOCKWISE to INCREASE / REDUCE the tempera-
ture of the hot water;
Fig. 14
• when the operation has been completed, screw
the protective panel back on.
5.4 CLOCK BATTERY REPLACEMENT
The electronic control unit is equipped with a lithium bat-
tery to provide the clock with an approximately three-year
autonomy period, after which replacing the battery may
prove necessary.
In case the machine has remained unutilised for a long
time, the clock can be blocked by proceeding as follows:
• with the machine off the display will read:
OFF
Fig. 15
• press the ENTER key for 5 seconds; the display
will read:
STOP CLOCK
The clock will start up again as soon as the machine is
plugged in once more.
