Everlast 1650201 Owner's Manual

Treadmill

Hide thumbs

Table Of Contents

1650201

OWNER'S MANUAL

ASSEMBLY‧OPERATION‧MAINTENANCE

WARRANTY‧PART ORDERING

▲CAUTION:

Exercise of a strenuous nature, as is customarily done on this equipment, should not

be undertaken without first consulting a physician. No specific health claims are made or implied as

they relate to the equipment.

IMPORTANT:

Read all instructions carefully before using this product. Retain this owner's

manual for future reference.

MAURICE PINCOFFS CANADA INC., 6050 Don Murie Street, Niagara Falls, Ontario L2E 6X8.

Table of Contents

Summary of Contents for Everlast 1650201

Page 1 1650201 OWNER’S MANUAL ASSEMBLY‧OPERATION‧MAINTENANCE WARRANTY‧PART ORDERING ▲CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not be undertaken without first consulting a physician. No specific health claims are made or implied as they relate to the equipment.
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Precautions……………………………………………………….. Before you begin………………………………………………………..Assembly………………………………………………………………..Operation and adjustment…….………………………………………..Folding……………………………………………………………………. Parts list…….………………………………………........Overview Drawing………………………………………………………. Trouble Shooting………………………………………………………… Treadbelt Adjustment……………………………………………………. Treadmill Lubrication ………………………………………………….. Cleaning and Maintenance……………………………………………… Training Guidelines …………………………………………………….. Exercise Routine…………………………………………………………. Warranty…………………………………………………………………. CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2010...
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY READ ALL INSTRUCTIONS BEFORE USING THIS TREADMILL ▲CAUTION: Before starting any exercise program, it is recommended that you consult your physician. ▲WARNING: Connect this unit to a properly grounded outlet only. ▲DANGER: To reduce the risk of electric shock, always unplug the treadmill from the electrical outlet immediately after using and before cleaning.
Page 4: Before You Begin
16. Never turn on treadmill while standing on treadbelt. Always hold the handrails while using the treadmill. Always return the treadmill to the slowest speed to provide for safe dismount and low speed restart. 17. To disconnect, turn all controls to the off position, then remove plug from outlet. 18.Do not attempt to raise, lower or move the treadmill until it is properly assembled.
Page 5 Thank you for purchasing our product. Even though we go to great efforts to ensure the quality of each product we produce, occasional errors and /or omissions do occur. In any event should you find this product to have either a defective or a missing part please contact us for a replacement.
Page 6 HARDWARE CHECK LIST #96. M5 x 10 m/m #95. Ø5/16”x19x1.5T Phillips Head Screw (6pcs) Curved Washer (8pcs) #94. 5/16” x15m/m #90. 3.5x12 m/m Button Head Socket Bolt (14pcs) Self Tapping Screw (4pcs) #93 Lubricant (1pc) #102. Safety Key (1pc) #98. M6 Allen Wrench (1pc) #97.
Page 7: Assembly Instruction
ASSEMBLY INSTRUCTION t will take two people to assemble your unit. Set the treadmill in a cleared area and remove all packing material. Do not dispose of the material until your assembly is completed. Note: The underside of your treadmill’s walking belt is coated with a lubricant.
Page 8 Step 3 Secure the right and left Upright (4,5) into the Frame Base with the 8pcs of 5/16”x15m/m Button Head Socket Bolts (94) and 4 pcs of 5/16" x 19 x 1.5T Curved Washers (95). Be careful not to pinch the computer cable when installing the Right Upright. Step 4.
Page 9 Step 5. Connect the Extension Computer Cable (37) with the Upper Computer Cable (36). Step 6. Secure the Console Assembly (39) into the Left & Right Uprights (4,5) with the 6pcs of 5/16”x15m/m Button Head Socket Bolts (94) and 4 pcs of 5/16" x 19 x 1.5T Curved Washers (95).
Page 10 Step 7. Secure the Left and Right Upright Covers (41, 40) to the Console Assembly (39) with the 4 pcs of 3.5x12m/m Self Tapping Screws (90). Step 8. Install the Frame Base Caps (44,43) onto the Frame Base. Secure with 6pcs of M5x10m/m Phillips Head Screws (96).
Page 11: Treadmill Operation
TREADMILL OPERATION Your treadmill features a walking belt coated with a lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or walking board. Such substances will deteriorate the walking belt and cause excessive wear. How to plug in the power cord. GROUNDING INSTRUCTIONS.
Page 12 MONITOR INSTRUCTIONS ▲CAUTION: Before operating the console, read the following precautions: • Do not stand on the walking belt when turning on the treadmill • Always wear the safety key • Adjust the speed in small increments to avoid sudden jumps in speed •...
Page 13 WINDOW DISPLAY DATA: SCAN: When lit, will scan through all the display information; each one for 5 seconds. SPEED: Displays the current belt speed from starting at 1.0Mph to 10.0Mph. TIME: Accumulates total workout time from 00:00 to 99:59. DISTANCE: Accumulates total workout distance from 0.00 to 99.99 miles.
Page 14 Quick-Start Operation: STEP 1: Attach the Safety key to wake display up (if not already on). The main window will show the initial display: P0. STEP 2: Press the START button to begin belt movement after a three second count down. Use the FAST/SLOW keys to adjust the desired speed (on console) at any time during training.
Page 15: Error Message
To Select a Program: Step 1: Press the ^ or v button to choose P1 ~ P5, each program has a preset speed value. Step 2: Press the ENTER button to set the count down time from 10:00 to 99:00; the preset value is 20:00.
Page 17: Folding
FOLDING AND MOVING YOUR TREADMILL Before folding the treadmill, ensure that the treadmill is at its lowest incline position. Turn the power switch off, located on the front of the motor cover and unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45lbs) in order to raise and lower the treadmill. To decrease the possibility of injury, bend your legs and keep your back straight while you are raising or lowering your treadmill.
Page 18 KEY NO. PART NO. DESCRIPTION O'TY 020101 Main Frame 020102 Frame Base 020103 Incline Bracket 020104 Left Handrail 020105 Right Handrail 020106 Console Support 020107 Outer Slide 020108 Inner Slide 0201009 Locking Knob Axle 020110 Bottom Motor Plate 020111 Belt Guide 020112 Running Deck 020113...
Page 19 KEY NO. PART NO. DESCRIPTION O'TY 020139-14 Power Cord Of Amplifier 39~14 020139-15 300mm_Speaker 39~15 39~16 020139-16 750mm_Speaker 39~17 020139-17 Sound Board 39~18 020139-18 Sound Board W/Cable 020139-19 39~19 Safety Switch Module W/Cable 020139-21 3×10mm_Self Tapping Screw 39~21 020140 Right Handrail Cover 020141 Left Handrail Cover 020142...
Page 20 KEY NO. PART NO. DESCRIPTION O'TY 020182 Ø19 x 10 x 1.5T_Flat Washer 020183 3/8"×2.0T_Split Washer 020184 Ø5×15×1.0T_Flat Washer 020185 M5_Raised Washer 020186 4x12m/m_Self Tapping Screw 020187 5x16m/m_Tapping Screw 020188 5x19m/m_Tapping Screw 020189 5x16m/m_Tapping Screw 020190 3.5x12m/m_Self Tapping Screw 020191 4x38m/m_Self Tapping Screw 020192 3.5x16m/m_Tapping Screw...
Page 23: Trouble Shooting
TROUBLE SHOOTING Problem Cause Correction Treadmill will not start Treadmill not plugged in Plug into three prong (grounded) outlet On / off switch not on Push the on/off button to on House circuit breaker tripped Reset or replace Treadmill reset switch tripped Reset treadmill reset switch see reset switch resetting Treadmill motor controller fuse...
Page 24: Treadbelt Adjustment
TREADBELT ADJUSTMENT The treadbelt has been factory pre-adjusted, however if during the operation: If T R E A D M ILL If Treadbelt slips during use slips during use. Treadbelt slips during use if the treadbelt is too loose: a) Tighten both rear roller adjusting bolts 1/4 turn clockwise using allen wrench.
Page 25: Treadmill Lubrication
TREADMILL LUBRICATION Your treadmill should require little maintenance other then periodically applying lubricant. Lubricating under the treadbelt will ensure superior performance and extend its life expectancy. HOW TO CHECK TREADBELT FOR PROPER LUBRICATION Lift one side of the treadbelt and feel the top surface of the treadboard If the surface is (slick) to the touch, then no further lubrication is required If the surface is dry to the touch, apply one packet of lubricant or half of the bottle of lubricant.
Page 26: Cleaning And Maintenance
CLEANING AND MAINTENANCE Care has been taken to assure that your treadmill has been properly adjusted and lubricated at the factory. It is not recommended that the user attempt service on the internal components instead seek service from an authorized service center. However, from time-to-time the outer surfaces may appear dull or dirty, following the instructions listed below will restore and preserve the original finish.
Page 27 RESET SWITCH RESETTING If your treadmill looses power or will not start, check the reset switch located on the front of the motor cover. If the white tab of the reset switch is not showing then the reset switch has not been tripped. If the white tab of the reset switch is showing, the reset switch has tripped.
Page 28: Training Guidelines
TRAINING GUIDELINES Exercise is one of the most important factors in the overall health of an individual. Listed among its benefits are: Increased capacity for physical work (strength endurance) Increased cardiovascular (heart and arteries/veins) and respiratory efficiency Decreased risk of coronary heart disease Changes in body metabolism, e.g.
Page 29 Specificity Different forms of exercise produce different results. The type of exercise that is carried out is specific both to the muscle groups being used and to the energy source involved. There is little transfer of the effects of exercise, i.e. from strength training to cardiovascular fitness. That is why it is important to have an exercise program tailored to your specific needs.
Page 30 The target is not a magic number, but a general guide. If you’re above average fitness, you may work quite comfortably a little above that suggested for your age group. The following table is a guide to those who are keeping fit. Here we are working at about 80% of maximum.
Page 31 Stretching should be included in both your warm up and cool down, and should be performed after 3- 5 minutes of low intensity aerobic activity or callisthenic type exercise. Movements should be performed slowly and smoothly, with no bouncing or jerking. Move into the stretch until slight tension, not pain, is felt in the muscle and hold for 20-30 seconds.
Page 33: Warranty
12 months from the date of purchase. All other obligations or liabilities, including liability for consequential damages are hereby excluded All of the parts for the Everlast treadmill, shown in figure can be ordered from: MAURICE PINCOFFS CANADA LTD. 6050 Don Murie Street, Niagara Falls, Ontario, L2E 6X8. When ordering parts, the parts will be sent and billed at the current prices.
