COLOR SCANNING SONAR FSV-24/24S
SAFETY INSTRUCTIONS .............................................................................i
SYSTEM CONFIGURATION........................................................................iii
EQUIPMENT LISTS .....................................................................................iv
1. MOUNTING THE EQUIPMENT.......................................................... 1-1
1.1 Mounting the Hull Unit ..................................................................................................... 1-1
1.2 Mounting the Display Unit................................................................................................ 1-8
1.3 Mounting the Transceiver Unit ....................................................................................... 1-14
1.4 Mounting the Power Supply Unit ................................................................................... 1-14
1.5 Grounding the Equipment.............................................................................................. 1-15
1.6 Installing Attachment Flange (option)............................................................................. 1-15
1.7 Mounting the Cable for Extension Kit (option)................................................................ 1-18
2. WIRING ............................................................................................... 2-1
2.1 How to Use the Crimping Tool, Pin Extractor ................................................................... 2-1
2.2 Location of Connectors.................................................................................................... 2-2
2.3 Monitor Unit..................................................................................................................... 2-4
2.4 Processor Unit................................................................................................................. 2-8
2.5 Transceiver Unit ............................................................................................................ 2-14
2.6 Power Supply Unit......................................................................................................... 2-17
2.7 Cable for Extension Kit.................................................................................................. 2-17
3. ADJUSTMENT AND CHECK ............................................................. 3-1
3.1 Hull Unit Check................................................................................................................ 3-1
3.2 Heading Adjustment ........................................................................................................ 3-4
3.3 Configuring Own Ship Mark............................................................................................. 3-6
3.4 Other SYSTEM Menu Items ............................................................................................ 3-8
3.5 CONE Board Setting in the Processor Unit.................................................................... 3-12
3.6 DIP Switch Setting......................................................................................................... 3-13
3.7 Testing TX/RX Independently at hull unit ....................................................................... 3-15
Check List.............................................................................................. AP-1
PACKING LISTS .......................................................................................A-1
OUTLINE DRAWINGS ..............................................................................D-1
SCHEMATIC DIAGRAMS ......................................................................... S-1
Installation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FSV-24 and is the answer not in the manual?

Questions and answers

Summary of Contents for Furuno FSV-24

  • Page 1: Table Of Contents

    Installation Manual COLOR SCANNING SONAR FSV-24/24S SAFETY INSTRUCTIONS ................i SYSTEM CONFIGURATION................iii EQUIPMENT LISTS ..................iv 1. MOUNTING THE EQUIPMENT............1-1 1.1 Mounting the Hull Unit ..................... 1-1 1.2 Mounting the Display Unit....................1-8 1.3 Mounting the Transceiver Unit ..................1-14 1.4 Mounting the Power Supply Unit ................... 1-14 1.5 Grounding the Equipment....................
  • Page 2 *00080916702* *00080916702* *00080916702* *00080916702* ( ( TATA TATA ) ) FSV-24/24S FSV-24/24S * 0 0 0 8 0 9 1 6 7 0 2 * * 0 0 0 8 0 9 1 6 7 0 2 * *IME13180J00* *IME13180J00*...
  • Page 3: Safety Instructions

    Water leakage can sink the vessel. Also confirm that the transducer will not loosen by ship's vibration. The installer of the equipment is solely responsible for the proper installation of the equipment. FURUNO will assume no responsibility for any damage associated with improper installation.
  • Page 4 CAUTION Maximum speed while the transducer is projected and being raised or lowered is as below, to prevent damage to the transducer. Projected Raising/ Lowering 1200 mm stroke Max. 18 kt Max. 15 kt 1600 mm stroke Max. 15 kt Max. 12 kt Observe the following compass safe distances to prevent interference to a magnetic compass:...
  • Page 5: System Configuration

    SYSTEM CONFIGURATION CONTROL UNIT MONITOR FSV-2401 UNIT FSV-2400 Local Supply Option AD Converter Gyrocompass AD-10 Loudspeaker Current Indicator Sub Monitor Current Echo Sounder, Indicator/Speed log Current Indicator, other E/S Interface PROCESSOR UNIT VI-1100A Navigator 1 FSV-2402/2402S If CS-170 is not installed, VI-1100A or Net Recorder Navigator 2 may be installed.
  • Page 6: Equipment Lists

    Type Code No. Q’ty Remarks Monitor Unit FSV-2400 21” color monitor Control Unit FSV-2401 w/cable Processor Unit FSV-2402 For FSV-24 FSV-2402S For FSV-24S Transceiver Unit FSV-241E Power Supply Unit FSV-242 Hull Unit FSV-243E 1200 mm stroke FSV-244E 1600 mm stroke...
  • Page 7 Options Name Type Code No. Q’ty Remarks Monitor Unit FSV-2400-10 With CP10-04501, FP03-06201, FP10-02202, Dust cover & 10S5207 (10 m cable) FSV-2400-30 With CP10-04501, FP03-06201, FP10-02202, Dust cover & 10S2075 (30 m cable) Control Unit FSV-2401-E-5 With FP10-02201 & 5 m cable FSV-2401-E-10 With FP10-02201 &...
  • Page 8 This page is intentionally left blank.
  • Page 9: Mounting The Equipment

    MOUNTING THE EQUIPMENT Mounting the Hull Unit Note1) The rise/lower control box of the hull unit contains motion sensor. Therefore, never drop the hull unit. Note2) Take care the handling of the transducer. Do not give a strong shock. 1.1.1 Location of hull unit Decide the location of the hull unit through consultation with the dockyard and ship owner.
  • Page 10 1300 Heater Insulator Maintenance space, example sonar compartment Note: After mounting the equipment, install stays for anti-vibration. See page 1-7.
  • Page 11 1.1.2 Shortening the retraction tank The retraction tank is 1300 mm in length when supplied. Shorten the tank as necessary so that the transducer is placed well below the keel when it is fully lowered. The following table provides guidelines for shortening the tank. Refer also to the retraction tank installation drawing at the back of this manual.
  • Page 12 1.1.3 Remarks for installation of retraction tank 1. Make, if possible, the installation location a double bottom structure. 2. Install, if possible, the tank on the keel where the tank can be most firmly fixed. 3. Install the reinforcement ribs as near as possible to the top of the retraction tank, allowing space for tightening of bolts and nuts.
  • Page 13 1.1.4 Installing hull unit on retraction tank After welding the retraction tank and allowing sufficient time for cooling, install the hull unit as follows: 1. Clean the hull unit flange, the O-ring and O-ring groove. Coat them with a slight amount of grease. Place the O-ring in position on the tank flange. 2.
  • Page 14 Hex. Nut Spring Washer Flat Washer Insulation Gasket (1) Insulation Gasket (2) Bow Mark Hull Unit Flange Insulation Gasket (1) O-ring Tank Flange Insulation Gasket (2) Flat Washer Hex. Bolt Hex. Nut Spring Washer Insulation Gasket (2) Flat Washer O-ring Insulation Gasket (1) Retraction Tank Flat Washer...
  • Page 15 1.1.5 Installing stays (anti-vibration measure) Install stays from the top of the hull unit to the ship’s hull. The stays should be angle iron with a size of 75X75X9 mm or more and at least two pieces should be used; one each to ship’s bow and stern directions. Install if possible, two more stays in ship’s transverse direction.
  • Page 16: Mounting The Display Unit

    Mounting the Display Unit The display unit is composed of the processor, monitor and control units. 1.2.1 Processor unit Mounting considerations When selecting a mounting location, keep in mind the following points: • The processor unit must be mounted upright. •...
  • Page 17 Mounting procedure 1. Unfasten two bolts from the bottom of the front side of the processor unit, and pull the unit toward you to separate the unit from the mounting base. 2. Fasten six bolts (M6x20, supplied as installation material) to install the mounting base.
  • Page 18 Mounting procedure 1. Drill four holes of 12 mm in diameter in the mounting location, referring to the outline drawing for mounting dimensions. 2. Unfasten two M4X10 screws to dismount the front cover. 3. Unfasten two sets of M10 bolts, plain washers and spring washers to separate the monitor from the mounting base.
  • Page 19: Control Unit

    Attaching the CRT filter 1. Attach two spacer (5x2.5, supplied) with screws (M5x10, supplied) to the location shown below. 2. Screw two hood retainer (supplied) into the filter (supplied). 3. Turn two washers (Ф12, supplied) into two hood retainer attached at step 2. 4.
  • Page 20 (2) Fixing without KB fixing plate 1) Drill four mounting holes of 6 mm diameter to fasten the control unit, referring to the outline drawing at the back of this manual. 2) Make a cutout in the mounting location large enough to accommodate the name plate so the control unit will lie flat.
  • Page 21 Passing the cable through the bottom of the control unit For permanent mounting ((2) and (3) above), the control cable can be passed through the bottom of the control unit. Do the steps in below. 1. Unfasten eight screws (M4) to remove the cover from the bottom of the control unit.
  • Page 22: Mounting The Transceiver Unit

    Mounting the Transceiver Unit The transceiver unit should be mounted on a mounting base (shipyard supply) whose dimensions are as shown in the outline drawing of the transceiver unit at the back of this manual. The transceiver unit should be reinforced against vibration by stays extending from the eyebolts on the top of the unit.
  • Page 23: Grounding The Equipment

    Grounding the Equipment The power supply unit, processor unit and hull unit have protective grounding. Ground the units with a ground wire (IV-8SQ, local supply) or copper strap to prevent electrical shock. Ground the monitor unit and transceiver unit with a ground wire (IV-8SQ, local supply) or copper strap fastened to the ship’s superstructure.
  • Page 24 Procedure 1. Clean the hull unit flange, O-ring and O-ring groove. Coat them with a slight amount grease. 2. (1200 mm stroke) Use 24 hex. bolts, 48 hex nuts, flat washers and spring washers to fasten the attachment flange to retraction tank. (1600 mm stroke) 24 bolts have already been fitted.
  • Page 25 Hex. Bolt Flat Washer Insulation Gasket (2) Hull Unit Flange O-ring Insulation Gasket (1) Insulation Gasket (2) Flat Washer Spring Washer Hex. Nut Attachment Flange O-ring Existing Tank Flat Washer Spring Washer Hex. Nut Attachment flange for 1600 mm stroke transducer, sectional view 1-17...
  • Page 26: Mounting The Cable For Extension Kit (Option)

    Mounting the Cable for Extension Kit (option) For extension of the transducer cable between the hull unit and the transceiver unit, use the extension cable kit (option). The kit is available in 5 and 15 meter lengths. Name: Cable for Extension Kit, Type: FSV-2451, Code No.: 000-067-030 Name Type Code No.
  • Page 27: Wiring

    WIRING How to Use the Crimping Tool, Pin Extractor A special crimping tool is necessary for connection of wires to the contact pins of the 38P connector. The pin extractor removes the contact pin from the connector body. This paragraph describes how to crimp and extract the contact pin. Crimping Tool Contact Pin Pin Extractor...
  • Page 28: Location Of Connectors

    Location of Connectors MONITOR UNIT 10S2076 (5/10 m) FSV-2400 10S2076 (5/10 m) CONTROL UNIT FSV-2401 10S2074 (10 m) or 10S2075 (30 m) CONTROL UNIT FSV-2401 Monitor Transceiver (Local supply) unit Monitor unit Control unit Monitor cable (Local supply) Monitor unit Control unit External monitor...
  • Page 29 Transceiver unit side 0.38m 0.07m Clamp point 0.46m 0.48m 0.5m 7.2m 10S2141 10S2078 10S2140 14.5m 13.3m 13.3m Clamp point 0.07m 0.28m Hull unit side Raise/lower control box of the hull unit side *: Cable length between the transceiver and hull unit.
  • Page 30: Monitor Unit

    Monitor Unit 2.3.1 Fabrication of monitor cable 10S2074 (10 m)/10S2075 (30 m) SHIELD ANTICORROSIVE SHEATH 11 12 1. GRY (No.1) 17. WHT/BRN 9. GRY (No.5) 25. GRN/BLU 2. BLK/WHT 18. WHT/PPL 10. BLK/BLU 26. GRN/BRN 3. GRY (No.2) 19. RED/GRN 11.
  • Page 31 Guide Pin A Guide Pin B Position No. Guide Pin B Guide Pin A (Small) (Large) Assembling 38P connector Positioning guide pins Guide pins of the connector identify the mating receptacle. They are; • Guide pin A (Large): 4 • Guide pin B (Small): 1 Assembling BNC connector (CN-A304 to 308) Housing Clamp Washer Nut 1.
  • Page 32 2.3.2 Control cable For FURUNO-supplied monitor, attach the cable from the control unit to the CN-A301 connector on the monitor unit as shown in the next section. For blackbox type, this cable should be connected to the CN-A103 connector in the...
  • Page 33 2.3.3 How to connect cables to the monitor unit Connect the monitor cable and control cable to the monitor (FURUNO-supplied monitor) unit as below. 1. Unfasten four screws (M4x10) at the rear of the monitor to loosen the cable cover.
  • Page 34: Processor Unit

    Processor Unit Cables (10S2074, 10S1258-1 and control cable) from the various units are connected to the CONE Board (10P6905) via the cable clamp (See page 2-2). CAUTION Divide cables attached to the back of the processor unit between right and left side. And then tie each group with a cable tie at the position 150 mm from connectors.
  • Page 35 Fabrication of connector 00-8016-038-313761HV (CN-A101) Anticorrosive Shield Sheath Vinyl Sheath Armor Core Insulating Tape After exposing cores, wind shield around the armor. Fabrication of connector 00-8016-038-313761HV Guide Pin A Guide Pin B Position No. Guide Pin B Guide Pin A (Small) (Large) Assembling 38P connector...
  • Page 36 Cable DPYCY-1.5 Armor Vinyl sheath Armor Vinyl sheath Taping Solder lead wire to armor and connect it to #1 pin of connector. Conductor Use cable DPYCY-1.5 S = 1.5 mm (Japan standard cable) ∅ = 1.56 mm or equivalent cable. Assembling connector NCS-253-P 2.4.3 Monitor cable (10S2074 or 10S2075)
  • Page 37 2.4.5 Optional equipment With connection of navigator and electronic fishing equipment, the function of the FSV-24 is expanded to include true motion presentation, target lock, echo sounder picture, FNZ marker presentation and digital indication of position, water temperature and depth.
  • Page 38 J5 (CIF1) : SRCN6A13-5P J7 (GYRO) : SRCN6A16-10P Cable with armor J8 (LOG) : SRCN6A13-3P J10 (FNZ) : SRCN6A21-10P J13 (EXT-KP) : SRCN6A21-10S 8 cm 2 cm 1 cm Armor Shield 3 mm Vinyl sheath Clamp fixing screw Solder unused cores and earth to braided shield.
  • Page 39 Synchronizing with echo sounder or other sonar To synchronize the transmission of the FSV-24 with an echo sounder or other type of sonar, make connections as shown below. For current driven KP Processor EXT-KP unit KP signal EXT-KP-IN-H EXT-KP-IN-C Sonar...
  • Page 40: Transceiver Unit

    Transceiver Unit 2.5.1 Fabrication of connector 00-8016-038-313761HV (CN-B101) Anticorrosive Shield Sheath Vinyl Sheath Armor Core Insulating Tape After exposing cores, wind shield around the armor. Fabrication of connector 00-8016-038-313761HV Shorten the unused wires appropriately and treat their ends with vinyl tape to prevent short circuit.
  • Page 41 2.5.2 Fabrication of power cable type DPYCY-4 (TB-B101) Fabricate the cable DPYCY-4 as below for connection to the power unit. Cable DPYCY-4 Armor Vinyl sheath Conductor S = 4 mm ∅ = 2.55 mm (Power unit side: 200) M4 (YEL) x2 FV5.5-4 Anticorrosive Vinyl sheath...
  • Page 42 2.5.4 Connection 1. Open the transceiver unit cover. 2. Plug the XH connectors at the end of signal cables (10S2140, 10S2141) into the proper receptacles in the transceiver unit, referring to the labels on the cables and numbers on the TRX board. 3.
  • Page 43: Power Supply Unit

    Power Supply Unit Connect the power cable DPYCY-4 or equivalent as below. For 220/230 VAC TB-D102 (AC IN) 230V 220V 100V Ship's mains Transceiver unit Lay the armor 110/115V of cable in the clamp. Lay the armor 100V TB-D101 (AC OUT) of cable in the clamp.
  • Page 44 3. Starting from the right side of the junction box, fix the cables by CSK clamp, pass them through cable clamps and connect XH connectors to the MTC board. Cable clamp Note: Capacitors not present on latest version of MTC board. CKS clamp Junction box, cover removed, front view Note: Capacitors not present...
  • Page 45 2.7.2 Raise/Lower Control Box Connect power cable (3φ) and the transceiver unit cable (10S2078) as shown below. CN-C101 Connect the transceiver cable (10S2078) to here. Cable TPYCY-4 Sheath U V W TB-C101 Connect the power cable Armor TPYCY-4 (Japan Industrial Standard) or the equivalent to this board.
  • Page 46 M4(yellow) x 3 FV5.5-4 Vinyl Sheath Armor sheath (Clamp here by cable clamp.) Power cable fabrication Note: LED Checking LED (inverse phase detector) shown in the above figure lights when the power cable is incorrectly connected. If the LED lights, reconnect the power cable after turning off the main switch.
  • Page 47: Adjustment And Check

    ADJUSTMENT AND CHECK Hull Unit Check After the installation, confirm that the LED in the raise/lower control box of the hull unit does not light. If it lights, turn off power at ship’s mains and reconnect two lines of U, V or W lines of the power cable. Note: Before conducting this check (at the dry dock) transmission must be stopped.
  • Page 48 3. Select INITIAL SETTING and press the [MENU] key. CAUTION THIS ITEM IS DEFINED AS NON- CHANGEABLE ITEM, ARE YOU SURE TO CHANGE IT TO CHANGEABLE ? 4. Select YES and press the [MENU] key. MENU QUIT OTHERS QUIT INITIAL SETTING QUIT MARK DISPLAY...
  • Page 49 How to check the hull unit 1. Press the POWER (|) switch on the control unit (for the display unit) to turn on the equipment. Confirm that the lamps above the ON and switches light. Transducer switches 2. Confirm that the 5V and UP lamps on the raise/lower control box are lit. 3.
  • Page 50: Heading Adjustment

    8. Check that LEDs on the panel of the raise/lower control box light as follows: a) UP, MD and DN LEDs light when corresponding limit switch is kicked. b) UP and DOWN LEDs light while UP and DOWN switches are pressed and extinguish when switches are released.
  • Page 51 SYSTEM MENU QUIT INTERFACE SETTING.. EXT DATA SETTING.. OWN SHIP MARK.. TEST&INITIALIZATION.. TRX SETTING 1.. TRX SETTING 2.. OTHERS.. SYSTEM menu 4. Use the trackball to select OTHERS and press the [MENU] key. 5. Select HEADING ADJUST and press the [MENU] key. MENU QUIT OTHERS...
  • Page 52: Configuring Own Ship Mark

    Configuring Own Ship Mark Set own ship’s dimensions and the location of the transducer to accurately display the own ship mark on the display. 1. Press the [MENU] key to display the SYSTEM menu. SYSTEM MENU QUIT INTERFACE SETTING.. EXT DATA SETTING.. OWN SHIP MARK..
  • Page 53 5. Select ! or " and then press the [MENU] key several times to set the ship’s length (15 to 150 m). 6. Select QUIT to finish the setting. 7. Set the SHIP’S WIDTH (5 to 30 m), TD POSITION 1 (5 to 50 m) or TD POSITION 2 (-10.0 to 10.0 m) similarly.
  • Page 54: Other System Menu Items

    Other SYSTEM Menu Items This section shows you how to set up external equipment. Default settings are underlined. 3.4.1 INTERFACE SETTING menu MENU QUIT QUIT INTERFACE SETTING NMEA 1 BAUD RATE : 4800 bps NMEA 2 BAUD RATE : 4800 bps CIF BAUD RATE : 4800 bps AUX BAUD RATE...
  • Page 55 3.4.2 EXT DATA SETTING menu MENU QUIT QUIT EXT DATA SETTING : CIF DATE&TIME : AD10S HEADING LOG PULSE : 200p/NM SPEED&COURSE : NMEA : GPS/DR SPEED SENSOR : NMEA LAT/LON : AUTO SEL. POSITIONING SENSOR WATER DEPTH : NMEA : NMEA WATER TEMP.
  • Page 56: Others Menu

    WATER DEPTH Select the input port for the depth data. (NONE, CIF, NMEA) WATER TEMP. Select the input port for the water temperature data. (NONE, CIF, NMEA) WATER CURRENT Select the input port for the water current data. (NONE, CIF, NMEA) WIND Select the format for the wind data.
  • Page 57 LANGUAGE Select the language. (JAPANESE, ENGLISH) HEADING ADJUST See “3.2 Heading Adjustment”. ES2 SELECT Select the equipment connected to the ES2 port among echosounder and net recorder. (ES, NET REC) ES DRAFT OFFSET When connecting echosounder, set the ship’s draft line to use depth from draft rather than depth from transducer.
  • Page 58: Cone Board Setting In The Processor Unit

    FSV-24. 3. For E/S 2, adjust R119 to suppress noise, and then adjust R167 so that the picture condition is similar to that of echo sounder connected to the FSV-24. 3.5.2 Adjusting the volume of audio alarm The audio alarm volume cannot be adjusted from the control unit.
  • Page 59: Dip Switch Setting

    DIP Switch Setting Processor unit, inside view 3.6.1 CIF2/NMEA2 connector interface selection The signal format of the CIF2/NMEA2 port at the back of the processor unit can be set for CIF or NMEA by DIP switch S2-8 on the IFES Board (10P6903). The default format is OFF (CIF).
  • Page 60 Input port Jumper J496 ES2/NET J497 Note: SIGOUT (AC signal) terminal and REC terminal (DC signal) in the output port are provided for FURUNO echosounder. Therefore, when using SIGOUT terminal, it is not necessary to change jumper setting. 3-14...
  • Page 61: Testing Tx/Rx Independently At Hull Unit

    Testing TX/RX independently at hull unit To check the Tx/Rx function of the hull unit independently, follow the steps below. Note: This test should not be done at the dry dock. The transducer will be damaged. 1. Turn ON DIP switch S3#1 on the TRCPU Board (10P6926) in the transceiver unit.
  • Page 62 This page is intentionally left blank.
  • Page 63: Connecting The External Interface Cs-120A

    CONNECTING THE EXTERNAL INTERFACE CS-120A When upgrading from the CSH-20 series sonar, the External Interface CS-120A can be used. Connect between the processor unit and the CS-120A as shown below. However, we recommend to connect external device to processor unit, instead of using the CS-120A, to avoid signal delay.
  • Page 64 2. Remove two upset screws, detach the plugs J503, J502, J501, J504, J506 and J507, thus pull out the power block. 3. Fix the power supply pcb (supplied) to the power block with spacers (supplied). 4. Connect two VH connectors (provided on the power block) to the power supply pcb.
  • Page 65 7. Connect between the processor unit and CS-120A as follows. Processor Unit POWER FOR CS-120A port CS-120A NJC-203-PM J201 +24V_H +24V_C CIF1 or NMEA2/CIF2 port CIF_TXD_H TD-H CIF_TXD_C TD-C CIF_RXD_H RD-H CIF_RXD_C RD-C SHIELD DSR-C DSR-H DTR-H 37-cores cable 10S1258 Note: Echosounder should be connected to the processor unit directly.
  • Page 66: Check List

    Check List Ship Name Date Location SCANNING TYPE FSV-24 RESULT SONAR Monitor unit (FSV-2400) Options Control unit (FSV-2401) CS-120A Processor unit (FSV-2402) VI-1100A Transceiver unit (FSV-241E) CS-170 Power supply unit (FSV-242) FSV-2451(5m),FSV2452(15m) Hull unit (FSV-243E/244E ) Reference Frequency 24KHz Transducer location...
  • Page 67 DATA SHEET 1 General check CK; DT: digital tester AT: analog tester OS:oscilloscope WC:watch Check item Content Check point Standard Judge Connection All connection 1.Transducer-transceiver unit Refer to should be checked 2.Processor unit-Transceiver unit installation refering to the 3.Processor unit-Control unit manual interconnection 4.Processor unit-Others equipment...
  • Page 68 DATA SHEET 2 DISPALY UNIT (FSV-2400 ) Check item Contents Check point Standard Result Judge Software Check software version on Self-check version the each board display DCON 1050714*** DUAL 1050703*** IFES 1050711*** 1050685*** TRCPU 1050717*** 1050665*** to 1050684*** TRANSCEIVER UNIT(FSV-241) Check item Contents Check point...
  • Page 69 DATA SHEET 3 User menu H-scan setting Range Gain Tilt Tx interval Pulse length Tx output TVG near TVG middle TVG far 2AGC Echo average Color Color curve Write by color response curve sheet. Display gain Delete color Far TVG curve Beamwidth-H V-scan setting Range...
  • Page 70 TRX setting1 TRX setting1 TX weight RX weight-H RX weight-V Auto filter Bandwidth COR start distance COR window length Gain at COR TRX setting2 TRX setting2 Near TVG curve-H Near TVG curve-V Near gain-H Near gain-V Pre TVG-H Pre TVG-V Post TVG-H Post TVG-V Absorption coeff.
