2.9 LED Indicators

LAN LEDs
Two LAN ports (LAN 1 and LAN 2) are located on the I/O back panel of the motherboard.
Each Ethernet LAN port has two LEDs. The yellow LED indicates activity, while the other
Link LED may be green, amber, or off to indicate the speed of the connection. Refer to the
tables below for more information.
Note: X11SSH-LN4F has additional LAN ports LAN3 and LAN4 as well.
LAN1-4 Activity LED (Right)
LED State
Color Status
Yellow Flashing
BMC
SP1
USB 2/3
BT1
LE3
JBT1
Intel PCH
I-SGPIO2
I-SGPIO1
USB 10
JSD2
(3.0)
USB 8/9
(3.0)
JSD1
USB 4/5
Definition
Active
4 3
2 1
VGA
LE1
USB 6/7 USB 0/1
LAN 2/4
LAN 1/3
JUIDB1
(3.0)
IPMI_LAN
LED BMC
BAR CODE
JPL3
JPL4
JPL2
JPL1
MAC CODE
IPMI CODE
J23
CPU
LED PWR
FANA FAN3
LAN1-4 Link LED (Left)
LED State
LED Color Definition
Off No Connection/10 Mbps
Amber 1 Gbps
Green 100 Mbps
COM 1
1. LAN1 LEDs
J7 J8
2. LAN2 LEDs
COM2
3. LAN3 LEDs (-LN4F only)
JPWR2
4. LAN4 LEDs (-LN4F only)
JPWR1
