X11SSH-F/-LN4F User Manual
Power SMB (I C) Header
2
The Power System Management Bus (I
fan, and system temperatures. Refer to the table below for pin definitions.
4-pin BMC External I
A System Management Bus header for IPMI 2.0 is located at JIPMB1. Connect the appropriate
cable here to use the IPMB I
definitions.
BMC
SP1
2
USB 2/3
BT1
LE3
JBT1
Intel PCH
I-SGPIO2
I-SGPIO1
USB 10
JSD2
(3.0)
USB 8/9
JSD1 (3.0)
USB 4/5
C) connector (JPI
2
Power SMB Header
Pin Definitions
Pin# Definition
1 Clock
2 Data
3 PMBUS_Alert
4 Ground
5 +3.3V
C Header
2
C connection on your system. Refer to the table below for pin
2
External I
Pin Definitions
Pin# Definition
1 Data
2 GND
3 Clock
4 NC
VGA
LE1
USB 6/7 USB 0/1
LAN 2/4
LAN 1/3
JUIDB1
(3.0)
IPMI_LAN
LED BMC
BAR CODE
JPL3
JPL4
JPL2
JPL1
MAC CODE
IPMI CODE
J23
CPU
LED PWR
FANA FAN3
C1) monitors the power supply,
2
C Header
2
COM 1
J7 J8
COM2
JPWR2
JPWR1
1
52
1. Power SMB Header
2. BMC External Header
