Standby Power
The Wake-On-LAN (WOL) header is located at JSTBY1 on the motherboard. Refer to the
table below for pin definitions.
Internal Speaker/Buzzer
The Internal Speaker (SP1) can be used to provide audible notifications using various beep
codes. Refer to the table below for pin definitions. Refer to the layout below for the location
of the internal buzzer.
LE1
JUIDB1
BMC
LED BMC
2
SP1
USB 2/3
BT1
LE3
JBT1
Intel PCH
I-SGPIO2
I-SGPIO1
USB 10
JSD2
(3.0)
USB 8/9
JSD1 (3.0)
USB 4/5
Wake-On-LAN
Pin Definitions
Pin# Definition
1 +5V Standby
2 Ground
3 Wake-up
Internal Buzzer
Pin Definitions
Pin#
1 Pos (+)
2 Neg (-)
VGA
USB 6/7 USB 0/1
LAN 2/4
LAN 1/3
(3.0)
IPMI_LAN
BAR CODE
JPL3
JPL4
JPL2
JPL1
MAC CODE
IPMI CODE
J23
CPU
1
LED PWR
FANA FAN3
51
Definition
Beep In
Alarm Speaker
COM 1
J7 J8
COM2
JPWR2
JPWR1
Chapter 2: Installation
1. Standby Power
2. Internal Speaker
