X11SSH-F/-LN4F User Manual

2.4 Memory Support and Installation

Note: Check the Supermicro website for recommended memory modules.
Important: Exercise extreme care when installing or removing DIMM modules to pre-
vent any possible damage.

Memory Support

The X11SSH-F/-LN4F motherboard supports up to 64GB of unbuffered (UDIMM) DDR4 ECC
2133/1866/1600/1333MHz memory in four memory slots. Populating these DIMM slots with
memory modules of the same type and size will result in interleaved memory, which will
improve memory performance.

DIMM Module Population Configuration

For optimal memory performance, follow the table below when populating memory.
Processors and their Corresponding Memory Modules
CPU#
CPU
Memory Module Population for Optimal Performance
Number of Memory Population Configuration Table
DIMMs (For memory to work properly, please follow the instructions below.)
2 DIMMs
DIMMB2/DIMMA2
4 DIMMs DIMMB2/DIMMA2, DIMMB1/DIMMA1
DIMM Slots
DIMM Type
per Channel
Unbuffered
2
DDR4 ECC
Corresponding DIMM Modules
DIMMA1 DIMMA2
Memory Module Population
POR Speeds Ranks per
(MHz) DIMM
2133,1866,
SR, DR
1600, 1333
Memory Module Population
Max Memory 4GB DRAM
Possible Technology
Single Rank 16GB
UDIMM (4x 4GB DIMMs)
Dual Rank 32GB
UDIMMs (4x 8GB DIMMs)
32
DIMMB1 DIMMB2
Layer
FW Base
Count
6 SPS
8GB DRAM
Technology
32GB
(4x 8GB DIMMs)
64GB
(4x 16GB DIMMs)
Supported
Voltage
1.2V1
