X11SSH-F/-LN4F User Manual
LED Indicators
•
Power/suspend-state indicator LED
•
UID/Remote UID LED
•
Fan failed LED
•
HDD activity LED
•
CPU/system overheat LED
•
LAN activiity LED
Other
•
RoHS
Dimensions
•
Micro ATX form factor (9.6" x 9.6") (243.84 mm x 243.84 mm)
Note 1: The CPU maximum thermal design power (TDP) is subject to chassis and
heatsink cooling restrictions. For proper thermal management, please check the chas-
sis and heatsink specifications for proper CPU TDP sizing.
Note 2: For IPMI configuration instructions, please refer to the Embedded IPMI Con-
figuration User's Guide available at http://www.supermicro.com/support/manuals/.
Motherboard Features
16
