Motherboard Features

CPU
•
Intel® Xeon® E3-1200 v5 and 6th Gen Core™ i3, Pentium and Celeron processors in an LGA 1151 (H4) socket. 80W
max TDP.
Memory
•
Four (4) 288-pin DIMM slots support up to 64 GB of SDRAM 72-bit DDR4 unbuffered ECC 2133/1866/1600/1333MHz
memory.
DIMM Size
•
16GB, 8GB, and 4GB, up to 64GB at 1.2V
Note 1: Memory speed support depends on the processors used in the system.
Note 2: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
•
Intel® PCH C236
Expansion Slots
•
One (1) PCI Express 3.0 x4 in x8 slot (PCH Slot 4)
•
One (1) PCI Express 3.0 x8 (CPU Slot 5)
•
One (1) PCI Express 3.0 x8 in x16 slot (CPU Slot 6)
•
One (1) M.2 Mini PCI Express 3.0 x2 connector
Network
•
Dual Gbe LAN ports (2x i210) for LAN1/LAN2
•
Quad Gbe LAN ports (4x i210) for LAN1-LAN4 (X11SSH-LN4F)
•
One (1) dedicated IPMI LAN located on the rear I/O panel
Baseboard Management Controller (BMC)
•
ASpeed 2400 Baseboard Controller (BMC) supports IPMI 2.0
Graphics
•
Graphics controller via ASpeed AST2400 BMC
I/O Devices
•
Serial (COM) Port
•
SATA 3.0
•
RAID (PCH)
•
Video (VGA) Port
Note: The table above is continued on the next page.
Motherboard Features
•
One (1) front accessible serial port header (COM2)
•
One (1) serial port on the rear I/O panel (COM1)
•
Eight (8) SATA 3.0 ports supported by Intel PCH (I-SATA0-ISATA7)
•
Two (2) SuperDOM connectors (I-SATA0 & I-SATA1)
•
RAID 0, 1, 5, and 10
•
One (1) VGA connection on the rear I/O panel
