Connector
Description
PCI-E (PCH) Slot 4
PCI-Express 3.0 x4in x8 Slot
PCI-E (CPU) Slot 5
PCI-Express 3.0 x8 Slot
PCI-E (CPU) Slot 6
PCI-Express 3.0 x8in x16 Slot
SP1
Internal Speaker/Buzzer
USB 0/1
Back Panel USB 2.0 Ports
USB 2/3, USB 4/5
Front Accessible USB 2.0 Headers
USB 6/7
Back Panel USB 3.0 Ports
USB 8/9
Front Accessible USB 3.0 Header
USB 10
USB 3.0 Type-A Header
VGA
Back Panel VGA Port
