X11SSH-F/-LN4F User Manual

Quick Reference Table

Jumper Description
J7 LAN4 LINK ACK (-LN4F only)
J8 LAN3 LINK ACK (-LN4F only)
JBR1 BIOS Recovery
JBT1 Clear CMOS
JI C1/JI C2 SMB to PCI Slots
2 2
JPB1 BMC Enable/Disable
JPG1 VGA Enable
JPL1-JPL4 LAN1-LAN4 Enable (LAN3/LAN4: for -LN4F only)
JPME2 Manufacturing Mode Select
JWD1 Watch Dog Enable
LED Description
LE1 Rear UID LED
LE3 PCI-E 3.0 M.2 LED
LEDBMC BMC Heartbeat LED
LEDPWR Onboard Power LED
Connector Description
BT1 Onboard Battery
COM1/COM2 COM1/COM2 Port Headers
Fan1-Fan4, FanA System/CPU Fan Headers
I-SATA0-I-SATA7 SATA 3.0 Connectors via Intel PCH (6Gb/s)
I-SGPIO 1/2 Serial_Link General Purpose I/O Connection Headers 1/2
IPMI_LAN Dedicated IPMI Gigabit (RJ45) Port
J23 M.2 Socket
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I
JL1 Chassis Intrusion Header
JOH1 Overheat LED Indicator
JPI C1 Power I
2
JPWR1 24-pin ATX Main Power Connector (Required)
JPWR2 +12V 8-pin CPU power Connector (Required)
JSD1/JSD2 SATA Disk On Module (DOM) Power Connectors
JSTBY1 Wake-On-LAN Enable Header
JTPM1 Trusted Platform Module/Port 80 Connector
JUIDB1 UID (Unit Identification) Switch
LAN1-LAN4 Gigabit (RJ45) LAN Ports (LAN3/LAN4: for -LN4F only)
Note: Table is continued on the next page.
C Header (for an IPMI Card)
2
C System Management Bus (Power SMB) Header
2
12
Default Setting
Off (Disabled)
Off (Disabled)
Pins 1-2 (Normal)
See Chapter 2
Pins 2-3 (Disabled)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Normal)
Pins 1-2 (Reset)
Status
Blue: On; Unit identified
Green: Blinking; Active
Green: Blinking; BMC normal
Green: Solid on; Power on
