Page 1: Short User Guide
PBX-System Short User Guide AC 14 analog Bedienung... -
Page 2: Get Started
Connect the plugs of your telephone equipment to the telephone system. The default setting of the AC 14 analog is that the first connection is extension 11 and the se- cond connection is extension 12. Plug the power supply into the 230V main socket. The red LED will flash while initialising and the light up. -
Page 3: Table Of Contents
Table of Contents ........................3 Important notes on using analogue equipment ................4 Pictograms and Buttons ......................5 LED´s of the AC 14 analog ......................5 Fax Switch ..........................6 Check Contents of delivery ......................7 Connections of AC 14 analog ...................... 7 Safety Notice .......................... -
Page 4: Important Notes On Using Analogue Equipment
Introduction Important notes on using analogue equipment Only analogue Apparatus which are approved to be connected to the Public Switched Tele- phone Network (PSTN) may be connected to the analogue side of the system. This includes all 2 wire telephones, answering -, fax machines, and modems. The system supports both dialling method Loop Disconnect (LD) or Dual Tone Multi Frequency (DTMF). -
Page 5: Pictograms And Buttons
Hash Button to dial Number Button for extension when entering digits, e.g. „9“ automatic line seizure is active LED´s of the AC 14 analog LED 1 LED 2 LED 3 Permanently lit Flashes System is operational System being initialised... -
Page 6: Fax Switch
What is referred to as a CNG tone is used to identify an incoming fax. The CNG tone is a peep tone with a frequency of 1100 hertz, lasts 0.5 seconds, and is repeated every 3 seconds. Your “AC 14 analog” is fitted with a fax switch which you can set conveniently in TK Suite or via a programming procedure. -
Page 7: Check Contents Of Delivery
- 1 manual - 1 connection cable to analogue exchange, - 1 CD-ROM with TK-Suite length 1,5 m - 1 PC-USB connection cable, lenght 3 m Connections of AC 14 analog Connection for Port 1 Port 2 USB Connection 3 4 5 6 7 8... -
Page 8: Safety Notice
Installation Select Location Install the System in a dry room free of any hazardous materials. Avoid sites near Air Conditioners, Radiators, Equipment with excessive high radiation, direct sunlight, excessive dust and the danger of liquid spillages such as Water or Chemicals. Ambient Temperature 5C to 30 C. -
Page 9: Connect Analogue Extensions
Connect the plugs of your telephone equipment to the telephone system. The default setting of the AC 14 analog is that the first connection is extension 11 and the se- cond connection is extension 12. Plug the power supply into the 230V main socket. The red LED will flash while initialising and the light up. -
Page 10: Connecting Extensions To Separate Sockets
If you want to connect your extensions to separate sockets, you will find the connection panel for the plug-in extensions on the downside of your AC 14 analog. Unplug the power pack from the 230 V mains socket before working on the connection panel. Replace the cover before plugging the power pack back into the mains socket. -
Page 11: Tk-Suite Server
Communication via PC Software Overview The enclosed CD-ROM contains the following software: TK-Suite Basic and the USB drivers. To be friendly to our environment we have not included printed version of the individual programs as help will be available in each program by just clicking on the question mark. System Requirements Following system features are required for the installation of the enclosed software - IBM or compatible PC with hard disc and CD-ROM drive... -
Page 12: Tk-Suite Bill
Communication via PC TK-Suite Set You can program the telephone system from your PC with TK-Suite Set. Call forwarding, ringing rhythms, day/night service and all ISDN parameters can be set quick and easy. With TK-Suite set you can save the telephone system configuration on your hard disc. -
Page 13: Install Tk-Suite
Communication via PC Install TK-Suite Start the installation routine of TK-Suite. After you selected the installation folder and start up group, you will be asked from the TK-Suite Basic installation routine if the application should be installed as Single Work Station, Server – or Client version. Select Single User if you would like to use the Telephone System with one PC only. -
Page 14: Install Tk-Suite
CTI is not possible with this setting. Afterwards you may select the type of connection to the system: Please note that the AC 14 analog can be connected to the PC via USB only. - Com1 or Com 2 if you want to communicate via the serial port with the system. -
Page 15: Cti - Computer Supported Telephony Via Tapi-Connection
Telephony-Interfaces. To connect the telephone system to this interface a Telephony Service Provider (TSP) from the hardware manufacturer, in this case AGFEO, is needed. The TSP is a driver which has to be installed on your PC. It will perform the requested TAPI functions and regulate the necessary data exchange between PC and the telephone system. -
Page 16: Driver Installation
“finish”. 7. Restart your computer to complete the installation. Deinstallation of Drivers Should you now longer require the drivers, then you may deinstall these. Remove the AC 14 analog in Control Panel. (Start/Control Panel/Add-Remove Programs) -
Page 17: Declaration Of Conformity
Communication via PC Declaration of conformity... - Page 18 Personal Notes...
- Page 19 Personal Notes...
- Page 20 Ident no. 1100612 Subject to change without AGFEO GmbH & Co. KG notice. No liability can be Gaswerkstr. 8 accepted for errors contained in D-33647 Bielefeld this document. Internet: http:// Printed in Germany www.agfeo.de 0054...
