t
A6
× 2
3 × 6mm 沉頭螺絲
Screw
A8
A21
× 2
×2
3 × 16mm 止付螺絲
Screw
A10
× 4
3 × 13mm 扁 頭螺絲
Screw
H4
× 2
5.8 × 21mm 拉 桿頭
Adjuster
P15
× 4
5.8 球 頭
Ball Connector
請參考圖示中擺臂上之字樣安裝
Attaching the arms per "A" "B" position as shown
y
A7
× 2
3 × 20mm 止付螺絲
Screw
A10
× 4
3 × 13mm 扁 頭螺絲
Screw
P15
× 4
5.8 球 頭
Ball Connector
H4
× 2
5.8 × 21mm 拉 桿頭
Adjuster
請參考圖示中擺臂上之字樣安裝
Attaching the arms per "A" "B" position as shown
t
前下擺臂組裝
Attaching Front Lower Arm
M3×16 止付螺絲
Screw
A6
3 × 6mm
D4
H4
D3
A6
3 × 6mm
y
後下擺臂組裝
Attaching Rear Lower Arm
﹡製作2份
Make 2
A7
3 × 20mm
H4
G2
H4
A8
3 × 16mm
G2
P15
P15
G2
P15
8
31.0mm
A10
3 × 13mm
34.5mm
A10
3 × 13mm
P15
MS-01D Pro
