MST MS-01D Pro Manual page 2

1
3 × 8mm 沉頭螺絲
Screw
A5
× 4
2
A5
× 4
3 × 8mm 沉頭螺絲
Screw
A15
× 3
2.5 × 6mm 半圓頭螺絲
Screw
A16
× 2
2 × 8mm 有頭螺絲
Screw
K1
A15
2.5 × 6mm
P1
馬達散熱座
× 1
Alum Moter Heat
Sink Mount
P3
主軸座支撐桿
× 1
Main Shaft Mount
Sipporting Bar
3
A5
× 4
3 × 8mm 沉頭螺絲
Screw
P17
× 2
4.8 × 5mm 球頭
Ball Connector
1
前側板底盤組合
Attaching Front Bulkhead
J1
A5
3 × 8mm
2
馬達座底盤組合
Attaching Motor Mount
P1
A5
3 × 8mm
3
後側板底盤組合
Attaching Rear Bulkhead
P3
K2
P17
4.8 × 5mm
A5
3 × 8mm
2
J2
A16
2 × 8mm
可將組裝說明中之塑膠主軸座替換為鋁合金
主軸座 (210135)。
The pastic main shaft mount could be
replaced to part no. 210135 alum main
shaft mount.
J2
J1
MS-01D Pro
