AudioArts Engineering R-5 Owner's Manual page 92

COMPONENT NO.
R-5 / Jun 02 R-5 / Jan 97
R-5 FRAME PARTS LIST
1.25 X 4 RED CLOCK PLEXI
MB5 LOADED INPUT SECTION CARD
OM5 LOADED OUTPUT SECTION CARD
SWR5 LOADED SWITCH CARD
FRAME FACE, PAINTED AND SCREENED
MB FACE, PAINTED AND SCREENED
MB REAR, PAINTED
CONSOLE BOTTOM PANEL, PAINTED
R5 SUPPORT BRACKET
R5 SPEAKER BRACKET
R5 ARMREST SUPPORT BRACKET
CONNECTOR KIT FOR R5
OAK SIDEPLATE LEFT
OAK SIDEPLATE RIGHT
30" OAK ARMREST
ALUMINUM CONTINUOUS HINGE, 72"X1.06"X.040"
UNSHIELDED WIRE
26 COND FLAT RIBBON CABLE
CABLE MOUNT MULTI-PIN CONNECTOR
MULTI-PIN CONNECTOR STRAIN RELIEF
MULTIMATE SOCKET CONTACT (LOOSE PACK)
6 PIN CABLE MOUNT MR PLUG
3 PIN .098" PLUG FOR #26 AWG
6 PIN .098" PLUG FOR #26 AWG
9 PIN .098" PLUG FOR #26 AWG
R-5 Frame Parts List – Sheet 1 of 2
(PCB is Wheatstone P/N 002560)
DESCRIPTION QTY
WS P/N
1 002463
002540
1
1 002541
6 002542
002570
1
002571
1
1 002572
1 002573
1 002575
002576
1
2 002577
1 002595
1 100049
100050
1
1 100054
.5 110024
150000
16
150083
5
1 230010
230012
1
230014
5
1 230026
2 230028
3 230031
26 230032
Page 9 - 28
