2. CHARACTERISTICS AND TECHNICAL DATA
The RELAX AUTOMATICA espresso coffee machines has the following features:
Technical Data:
Depth: 415 mm
Width: 280 mm
Height: 390 mm
Weight: 21 kg
3. SAFETY RECOMMENDATIONS AND RULES
Follow these rules carefully:
! the RELAX AUTOMATICA espresso machine should only be used for the purpose for which it was made
! improper use of the machine can cause damage to persons and property for which the manufacturer cannot be held responsible
! always contact a qualified service center or the manufacturer for operations other than those described in the instruction book and for
all types of repairs
! make sure the mains voltage is the same as the data on the rating plate
! make sure the electric power system is compatible with the data on the rating plate
! the coffee maker should be well and safety grounded. Have the system checked if you have any doubts
! make sure the power system is equipped with a safety cutoff that works properly and that the cross section of the cables is sufficient
for the power absorbed
! for any type of malfunction or problems not specified here, unplug the machine and do not attempt to check and/or repair it yourself.
Contact a qualified service center or the manufacturer
! do not fill the tank with water when the machine is plugged in
! make sure there is water in the tank when the machine is operating
! never place your hands or other parts of the body in the path of the water/steam nozzle. Hot water and steam can cause serious
burns
! never place your hands or other parts of the body or any other object inside the machine when it is plugged in
! never touch the machine with wet hands or feet
! never touch the hot parts of the machine (bottom of coffee distributor and water/steam nozzles)
! before performing any routine maintenance make sure the machine is unplugged, without pulling the power cable, or that the main
circuit breaker is off
! if the power cable should be damaged and have to be replaced, order a new cable from the manufacturer and/or its service center
! never immerse the coffee machine in any type of liquid
! do not use detergents or abrasive substances to clean the machine
! do not leave the machine exposed to atmospheric agents
! do not leave the machine within reach of children or people who are not capable of using it
! keep the coffee maker away from any heat sources
4. INSTRUCTIONS FOR THE USER
4.1 Starting the machine
To start the RELAX AUTOMATICA espresso coffee maker, follow the instructions below:
•
open the external packing and take the machine out. Inspect the machine to ascertain that it is intact and in good condition.
Check for the presence of all the accessories supplied with the machine (see paragraph 1.1)
•
position the machine on a flat surface
•
remove the cover and take out the water tank (located inside the machine) and rinse it
•
fill the container with clean water, return it to its housing and insert the silicon tubes. Close the cover on the machine
•
plug in the machine
•
switch the machine on with the main switch (1). The power ON light (2) will be lit
At this point the RELAX AUTOMATICA coffee machine is ready for use.
•
coffee maker in chrome-plated brass
•
all AISI 304 stainless steel construction
•
water/steam nozzle in chrome-plated copper
•
boiler in nickel-plated brass
•
mechanical overpressure with drip tray
•
adjustable pressure switch
•
water level sensor
•
internal exchanger for distribution of water/coffee
•
copper pipes for water connections
•
solenoid valve
•
electronic unit with automatic water refill sensor
•
micro switch for automatic cutoff of machine in case of lack of water in tank
•
four possible dosage selections and continuous erogation
Pump:
12-14 atm
Tank:
3 l
Power:
1400 W
Voltage: 230V-50Hz
115V-60Hz
8
