2. CHARACTERISTICS AND TECHNICAL DATA

The MAVERICK PLUS espresso coffee machine has the following features:
•
built-in coffee grinder with instant grinding
•
fully stainless steel construction
•
stainless steel cup rack warmer
•
drip tray and cup rack in stainless steel
•
coffee distributor with chrome-plated cup ring
•
internal water/steam tap in brass with safety by-pass
•
chrome-plated copper water/steam nozzle
•
brass boiler
Zaffiro Bis technical Data:
Depth: 290 mm
Width: 370 mm
Height: 360 mm
Pump: 12-14 atm
Tank: 3 l

3. SAFETY RECOMMENDATIONS AND RULES

Follow these rules carefully:
! the MAVERICK PLUS espresso machine should only be used for the purpose for which it was made
! improper use of the machine can cause damage to persons and property for which the manufacturer
cannot be held responsible
! always contact a qualified service center or the manufacturer for operations other than those
described in the instruction book and for all types of repairs
! make sure the mains voltage is the same as the data on the rating plate
! make sure the electric power system is compatible with the data on the rating plate
! the coffee maker should be well and safety grounded. Have the system checked if you have any
doubts
! make sure the power system is equipped with a safety cutoff that works properly and that the cross
section of the cables is sufficient for the power absorbed
! for any type of malfunction or problems not specified here, unplug the machine and do not
attempt to check and/or repair it yourself. Contact a qualified service center or the manufacturer
! do not fill the tank with water when the machine is plugged in
! make sure there is water in the tank when the machine is operating
! do not change the grinding parameters when the coffee grinder is running
! do not forget to turn the steam switch off after using the steam function
! never place your hands or other parts of the body in the path of the water/steam nozzle. Hot water
and steam can cause serious burns
! never place your hands or other parts of the body or any other object inside the machine when it
is plugged in
! never touch the machine with wet hands or feet
! never touch the hot parts of the machine (bottom of coffee distributor and water/steam nozzles)
! before performing any routine maintenance make sure the machine is unplugged, without pulling
the power cable, or that the main circuit breaker is off
! if the power cable should be damaged and have to be replaced, order a new cable from the
Power: 1000 W
Weight: 13 kg
Voltage: 230V-50Hz
115V-60Hz
12
manufacturer and/or its service center
! never immerse the coffee machine in any type of liquid
! do not use detergents or abrasive substances to clean the machine
! do not leave the machine exposed to atmospheric agents
! do not leave the machine within reach of children or people who are not capable of using it
! keep the coffee maker away from any heat sources

4. INSTRUCTIONS FOR THE USER

4.1 starting the machine

To start the MAVERICK PLUS espresso machine follow the instructions below:
•
open the external packing and take the machine out. Inspect the machine to ascertain that it
is intact and in good condition. Check for the presence of all the accessories supplied with the
machine (see paragraph 1.1)
•
position the machine on a flat surface
•
remove the cover and take out the water tank (located inside the machine) and rinse it
•
fill the container with clean water, return it to its housing and insert the silicon tubes. Close the
cover on the machine
•
plug in the machine
•
press the main circuit breaker (1). The main power on light (2) and the coffee light (4) will go on
Perform the following operations every time you switch the machine on and every time
you draw steam:
•
place a container under the water/steam nozzle (11)
•
turn the knob on the water/steam tap (10) counter-clockwise 
•
press the coffee switch (3). Water will come out of the water/steam nozzle (11)
•
press the coffee switch again (3)
•
turn the water/steam knob (10) clockwise  to close the tap
•
wait about 3-4 minutes until the machine is pressurized and the coffee light (4) goes off
Now the MAVERICK PLUS coffee machine is ready to use

4.2 Use of the coffee grinder

With the machine on:
•
pour coffee beans into the coffee grinder container (14)
•
The numbered label on the coffee container (14) refers to the different degrees of grinding. 0 is the
finest, 10 is the coarsest
The coffee grinder is set for optimum grinding which is level 3 on the label. For various reasons, the
type of coffee, moisture... it may be necessary to change the setting
! do not change the setting on the coffee grinder while it is in use
•
if you want to change the grinding setting, hold the ratchet down (17) and turn the coffee
container (14) until you have the desired grinding. For coarser coffee turn the coffee container
(14) counter-clockwise , and for finer grinding turn it clockwise 
•
release the ratchet (17) to lock the setting
13
