Instruction Manual
P-47D THUNDERBOLT EP
Requires : 5-channel radio w/ 5 micro servos,
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
THE WORLD MODELS
MANUFACTURING CO., LTD.
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY(ARF)SERIES
MADE IN CHINA
www.theworldmodels.com
Outrunner Motor KM0283010
w/ Propeller Adaptor HW2340100,
20A brushless ESC, 3 cells 11.1V
2100 mAh Li-Po battery & charger.
S p ecifica tio n s
* Specifications are subject to change without notice.*
INSTRUCTION MANUAL
39.5 in / 1000 mm
282 sq in / 18.2 sq dm
31 oz / 880 g
34 in / 870 mm
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for THE WORLD MODELS P-47D THUNDERBOLT EP
Summary of Contents for THE WORLD MODELS P-47D THUNDERBOLT EP
- Page 1 INSTRUCTION MANUAL P-47D THUNDERBOLT EP Requires : 5-channel radio w/ 5 micro servos, Outrunner Motor KM0283010 w/ Propeller Adaptor HW2340100, 20A brushless ESC, 3 cells 11.1V 2100 mAh Li-Po battery & charger. S p ecifica tio n s Wing Span 39.5 in / 1000 mm...
-
Page 2: Before You Begin
P-47D THUNDERBOLT EP INDEX BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-P.9 SAFETY PRECAUTIONS BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly. - Page 3 Parts List 1. MAIN WING -- 1 pc. 8. PUSHROD Ø1.4x477mm w/ Threads (For Elevator) -- 1 pc. FUEL TUBE d2xD4x4mm -- 1 pc. 2. RETRACTABLE LANDING GEAR -- 1 pair CLEVIS -- 1 pc. SCREW KA2.3x8mm -- 8 pcs COLLAR Ø2.6mm w/ Set Screw -- 2 pcs 9.
-
Page 4: Retractable Landing Gear
Main Wing Apply instant type CA glue to both sides of each hinge. Aileron Servo Lead Bottom View Aileron Servo Lead Retractable Landing Gear Bottom View... -
Page 5: Retract Servo
Please refer to the attached sheet for linkage connector installation. Retract Servo Linkage connector To R-Side 16mm Travel To L-Side 16mm Travel Wheels Down Position Wheels Up Position Ø1mm pilot holes for World Models tri-horn are pre-drilled. Please look for pin-hole Aileron Servo marks at under side of control surfaces. -
Page 6: Rudder Pushrod
Vertical Fin, Rudder & Tail Landing Gear PA2x8mm Screw M2 Nut PM2x8mm Screw Apply instant type CA glue to both sides of each hinge. PA2x8mm WHEEL Ø23mm Plastic Collar M2 NUT PM2x8mm C=C' Bottom View Completed Ø1mm pilot holes for World Models horn are pre-drilled. Please look Rudder Pushrod for pin-hole marks at under side of control surfaces. -
Page 7: Elevator Pushrod
Elevator Pushrod Ø1mm pilot holes for World Models horn are pre-drilled. Please look for pin-hole marks at under side of control surfaces. Bottom View TWM PL8210010 CLEVIS WRENCH Pushrod Clevis Ø1.4x477mm Fuel Tube d2xD4x4mm 55mm 12mm Outrunner Motor / Cowling KP0011310 Solder Solder... - Page 8 Radio equipment Install and arrange the Elevator Pushrod Fuel Tube Elevator Servo Battery Ø1.4x477mm d2xD4x4mm servo as shown in the diagram. Front Straper Rudder Pushrod Sponge Receiver Rudder Servo Ø1.4x475mm Double-Sided Tape 20A ESC Battery Battery Tie Completed Main Wing PM2.5x20mm NYLON BOLT Front Front...
- Page 9 Canopy Pilot PWA2x8mm Screw Canopy PWA2x8mm 1.5mm Wing Setting Adjust the wing and fuselage configuration as shown in the diagrams. A=A' B=B' C=C' D=D'...
- Page 10 # Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. is specially designed to be powered by KM0283010 Outrunner Motor. P-47D THUNDERBOLT EP # Make sure the air field is spacious, never fly the plane too close to people and never get too close to a running propeller.
- Page 11 LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
- Page 12 http://www.theworldmodels.com E242XMPO18110811...
