L :
IST OF ErrOrS
A rattling sound from the closed part of the mixer.
The mixer starts "striking" when kneading dough
which normally causes no problems.
The mixer changes its speed by itself.
The minimum and the maximum speeds are changing.
The bowl is too tight or too loose.
The tool hits the sides of the bowl.
The tool hits the bottom of the bowl.
Prior to a possible repair or adjustment, switch off the mixer by disconnecting the power cable.
A
djuSTmENT OF SpECIAL v
The distance (X) (Fig. 6) is only indicative as it depends
on the tolerance of the special V-belt.
1. Start by tightening the v-belts (
2. Tighten the special V-belt (A) by moving one or two
washers from (V) to (T).
3. Start the mixer and leave it running while the nut (U)
is tightened. Do not tighten it too much.
4. On the front pulley set the stud (E) on the varispeed
collar (F) must be placed inside the lower fork (G) and
on the rear pulley set outside the fork for belt tightener
(B), (both must point backwards).
5. Tolerances in the transmission might cause that the
special V-belt (A) is hitting the pins of the pulley sets
when the speed has been adjusted. In such cases
the distance (X) must be reduced.
6. Then follow the section:
"Adjustment of speed"
- :
BELT
*
).
p

OSSIBLE SOLuTION

Adjustment of special v-belt
Adjustment of special v-belt
Adjustment of special v-belt
Adjustment of speed.
Adjustment of bowl fixing
Adjustment of bowl centering
Adjustment of bowl height
A
djuSTmENT OF SpEEd
1. The stop screws (J) (Fig. 6) on the speed lever
should be adjusted so that the measurement (H) is
1-2 mm on the front and the rear pulley, at low and
high speed, respectively. Tighten the counter nuts
(K) when the speed is correctly adjusted.
2. Tolerances in the transmission might cause that the
special V-belt (A) is hitting the pins of the pulley sets
(Z) when the speed has been adjusted In such cases
the distance (X) must be reduced, see "Adjustment
of special v-belt", and the speed must be readjusted.
10
:
:
