ENFORCER DP-236Q Manual

ENFORCER Wireless Video Door Phone

Troubleshooting:

• Make sure the "ON/OFF" button was pressed.
The monitor's screen is blank. • Recharge the monitor's battery.
• Plug the charger directly into the monitor.
• Check that the volume is turned up.
The monitor does not ring. • Check that the monitor is in standby mode.
• Check that the monitor is placed in the mounting bracket.
The monitor's screen turns on, but
• Check that the monitor has been paired with the camera.
does not display the camera's
• Check that the monitor is within range of the camera.
image.
• Adjust the monitor's display brightness (see Operating the
The monitor's screen image quality is • Clean the camera's lens using a soft, clean cloth.
poor.
• Change the position of the camera.
• Move the monitor away from microwaves, television, lamps,
The monitor's "ON/OFF" button does • Check the wiring between the camera and the optional
not unlock the door's optional locking
device.
• Check that the unit is in two-way communication.
IMPORTANT: Users and installers of this product are responsible for ensuring this product complies with all national, state, and local laws
and statutes related to monitoring and recording audio and video signals. SECO-LARM will not be held responsible for the use of this product
in violation of any current laws or statutes.
WARNING: Stop using the camera if you see a malfunction such as smoke or unusual heat, as it could cause fire or electric shock. Do not
open the case of this device, as there are no field-serviceable components inside.
FCC COMPLIANCE STATEMENT: DP-236-CQ FCC ID:K4E236CQ
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Notice: The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted.
Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user's authority to
operate the device.
WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in normal service for a period
of one (1) year from the date of sale to the original customer. SECO-LARM's obligation is limited to the repair or replacement of any defective
part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration,
improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating
properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser's exclusive remedy, shall be limited to replacement or repair only, at SECO-LARM's
option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential personal or property damages of any
kind to the purchaser or anyone else.
NOTICE: The information and specifications printed in this manual are current at the time of publication. However, the SECO-LARM policy is
one of continual development and improvement. For this reason, SECO-LARM reserves the right to change specifications without notice.
SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2015 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or in part, without
the written permission of SECO-LARM.
U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
12
Wireless Video Door Phone on pg. 9~10).
and other potential sources of electromagnetic interference.
door locking device.
DP-236-MQ FCC ID:K4E236MQ
Website: www.seco-larm.com
E-mail: sales@seco-larm.com
MiDP-236Q_150319.docx
SECO-LARM U.S.A., Inc.
Wireless Video Door Phone
• Wireless operation – camera and monitor can
operate from up to 492ft (150m)
• Remotely and securely talk to visitors and
unlock doors or gates via the monitor
• Lightweight monitor can be carried around the
premises while talking to the visitor
• Connect up to two additional monitors
• Camera includes a built-in PIR sensor that
activates the camera and takes photos of the
visitor when he or she approaches
1
Second and third monitors sold separately.
2 Line-of-sight range. Actual range may vary depending on the installation and operating environment.
PICKN1
DP-236Q
Manual
• Camera has built-in IR LEDs for nighttime
2 away operation
• Monitor includes a kickstand and a charging
base
• Camera powered by 9~16 VAC/5~16 VDC
• Monitor front door at any time
1
• Egress input
• 120° wide field of view
• Adjustable camera pan and tilt angle—up to
20° from centerline in any direction—to allow
for mounting variations
1
