Installation Manual
ENFORCER
E-920A
Voice Dialer
Summary
: The E-920A Voice Dialer will automatically dial up to four
telephone numbers and deliver one of two different messages when
triggered by an alarm system.

HOW IT WORKS

When triggered by an alarm system, the
E-920A Voice Dialer can dial up to four
telephone numbers and/or pager
numbers. Each number can contain up
to 32 digits (including "pound" tones and
"pauses" used in pager numbers).
When the dialer is activated, the LCD will
show the numbers dialed at each step of
the dialing process. When the dialer
makes a connection, one of two possible
16-second voice messages, which the
user can record to respond to one or two
trigger inputs, will be delivered twice to
ensure the full message is received. This
process will repeat for each number
stored. If within 8 to 10 rings there is no
WARRANTY:
The ENFORCER 920A Voice Dialer is warranted against defects in
material and workmanship while used in normal service for a period of one (1) year from the
date of sale to the original customer. Our obligation is limited to the repair or replacement of
any defective part if the unit is returned, transportation pre-paid, to SECO-LARM.
SECO-LARM
SECO-LARM
SECO-LARM
SECO-LARM
SECO-LARM
U.S.A., Inc.
U.S.A., Inc.
U.S.A., Inc.
U.S.A., Inc.
U.S.A., Inc.
®
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
®
connection, the E-920A will automatically
dial the next programmed number.
As soon as the dialer has attempted to
dial each number one time, if the unit is
still in the alarm state, the dialer will
attempt to call the previous unanswered
or busy numbers up to 8 more times,
rotating through all unanswered
numbers until the full message was
delivered to each number two times.
Note: If the number of a voice pager
service which requires operator
assistance is used, the service should
be notified in advance regarding the
meaning of the message.
miE920A2004b_pdfb.pmd
Website: www.seco-larm.com
E-mail: sales@seco-larm.com
PIKVR1
Page 1
