DP-T100-2Q
DP-T100-1Q
Features:
• Simple and easy setup
• Encrypted transmission offers security
and protection
• Range up to 1,000ft (300m)*
• 4 Selectable channels
• Connect up to 16 wireless intercoms
• Each intercom has adjustable volume
• Indicator LEDs show mode and status
*Line-of-sight range. Actual range may vary depending on the installation and operating environment.
Wireless Intercom
Wireless Intercom Starter Kit – 2 Intercoms
Wireless Intercom – Single Intercom
Manual
• Powered by batteries (alkaline or rechargeable)
or power adapter (both not included)
• 4 Communication modes: full broadcast to all
stations, talk on a single channel, private talk,
and hands free
• Fail-safe design: if an intercom loses
connection it automatically reconnects to other
intercoms
®
Advertisement
Table of Contents
Related Manuals for ENFORCER DP-T100-2Q
Summary of Contents for ENFORCER DP-T100-2Q
-
Page 1: Wireless Intercom
Wireless Intercom Manual DP-T100-2Q Wireless Intercom Starter Kit – 2 Intercoms DP-T100-1Q Wireless Intercom – Single Intercom Features: • Simple and easy setup • Powered by batteries (alkaline or rechargeable) or power adapter (both not included) • Encrypted transmission offers security and protection •... -
Page 2: Table Of Contents
Notes ............................7 Also Available..........................8 Introduction: The ENFORCER Wireless Intercom is a simple and secure way to communicate between multiple intercoms (up to 16 units, total) within an area of up to 1,000ft (300m). The wireless intercoms operate on 4 channels and can either broadcast to all intercoms or to select intercoms on the same channel. -
Page 3: Overview
ENFORCER Wireless Intercom Overview: Channel selector Transmission Indicator LED Volume up Channel indicator LEDs Lock button/LED Volume down/hibernate Call button Privacy button/LED Hands-free button/LED Talk button Antenna DC Jack Pairing button Power On/Off NOTE: Intercoms can handle multiple channels communicating simultaneously without interference. -
Page 4: Power Controls
ENFORCER Wireless Intercom Power Controls: Power Switch Turn the unit on by sliding the power switch to the on position. The transmission indicator LED will flash and the channel indicator will blink to indicate the unit is searching for a signal. Once a signal is found, the channel indicator will stop blinking and the unit will click. -
Page 5: Basic Controls And Modes
ENFORCER Wireless Intercom Basic Controls and Modes: Call Button Press the call button to ring all intercoms on the same channel (or all channels if in broadcast mode (see "Broadcast Mode" below). Talk Button Press and hold the talk button to speak. The conversation will be heard by all intercom units on the same channel. -
Page 6: Operation
ENFORCER Wireless Intercom Operation: To use the ENFORCER Wireless Intercom system, it is helpful to understand a few principles. General Conversations 1. Press the call button once and all other units on the same channel (or all channels when in broadcast mode –... - Page 7 ENFORCER Wireless Intercom Operation (Continued): To answer a call that you wish to be private: 1. If you activate the privacy mode (or have already activated it) and press talk within 10 seconds of hearing a call ring, a private conversation is established with the caller after the first return message from the other unit.
-
Page 8: Also Available
ENFORCER Wireless Intercom Also Available from SECO-LARM ® Hands-Free Video Door Phone Wireless Desktop Wireless Video Door Phone Transmitter DP-236Q DP-234Q SD-862T-GWSQ 1-Button, 1-Channel Handheld 1-Channel RF Transmitter 1-Channel RF Receiver RF Transmitter SK-910RBQ SK-919TP1H-BUQ SK-919TD1S-UPQ Receivers and Transmitters also available in 2, 3, and 4 channel versions.
