Icom IC-FR3000 Service Manual page 99

[LOGIC UNIT]
REF ORDER
NO. NO.
W4 8900009230 CABLE
W5 8900008740 CABLE
W7 7030003860 S.JUMPER
W8 7030007150 S.JUMPER
W10 8900009270 CABLE
W11 8900009270 CABLE
W12 7030003860 S.JUMPER
W13 7030003860 S.JUMPER
W14 7030003860 S.JUMPER
W15 7030003860 S.JUMPER
W16 7030003860 S.JUMPER
W17 7030003860 S.JUMPER
W18 7030003860 S.JUMPER
W19 7030003860 S.JUMPER
W20 7030003860 S.JUMPER
EP1 0910056104 PCB
EP2 6910014900 BEAD
EP3 6910014890 E.OTHER
DESCRIPTION
OPC-908 (P=1 N=10 L=60)
OPC-867 (P=1 N=24 L=60)
ERJ3GE JPW V
MCR50JZHJ JPW
OPC-912 (P=1 N=22 L=70)
OPC-912 (P=1 N=22 L=70)
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
B 5654D
FRC-50-12-6.5
FRC-WC1
[RX UNIT]
REF ORDER
NO. NO.
IC1 1190000450 S.IC
IC2 1110003490 S.IC
IC3 1180000420 S.IC
IC4 1140005990 S.IC
IC5 1110002750 S.IC
IC6 1180000420 S.IC
IC7 1180000430 S.IC
Q1 1530003820 S.TRANSISTOR
Q3 1560000670 S.FET
Q6 1530001950 S.TRANSISTOR
Q7 1530001950 S.TRANSISTOR
Q8 1530002920 S.TRANSISTOR
Q9 1530003270 S.TRANSISTOR
Q14 1530002920 S.TRANSISTOR
Q15 1520000270 S.TRANSISTOR
Q16 1530002060 S.TRANSISTOR
Q18 1560000540 S.FET
Q19 1590000440 S.TRANSISTOR
Q20 1510000510 S.TRANSISTOR
Q21 1530002060 S.TRANSISTOR
D1 1750000070 S.DIODE
D3 1720000640 S.VARICAP
D4 1720000640 S.VARICAP
D6 1720000640 S.VARICAP
D7 1720000640 S.VARICAP
D15 1750000140 S.DIODE
D16 1750000140 S.DIODE
FI1 2030000201 S.MONOLITH
FI5 2020001030 CERAMIC
FI6 2020001040 CERAMIC
X1 6070000150 S.DISCRIMINATOR CDBCB455KCAY24-R0
X2 6050011470 XTAL
X3 6050011480 S.XTAL
L1 6200007670 S.COIL
L2 6200010290 S.COIL
L3 6200010290 S.COIL
L4 6200007700 S.COIL
L6 6200010290 S.COIL
L7 6200010290 S.COIL
L8 6200010490 S.COIL
L9 6200010490 S.COIL
L10 6200010490 S.COIL
L11 6200008730 S.COIL
L14 6200005510 S.COIL
L20 6200010300 S.COIL
L21 6200007230 S.COIL
L22 6200007710 S.COIL
L23 6200007680 S.COIL
L24 6200007680 S.COIL
L25 6200007230 S.COIL
L27 6200007230 S.COIL
L29 6200007230 S.COIL
L30 6200007230 S.COIL
L31 6200010300 S.COIL
L32 6200007670 S.COIL
L33 6200007340 S.COIL
L35 6200007820 S.COIL
L39 6200007680 S.COIL
L40 6200010300 S.COIL
L41 6200009940 S.COIL
L42 6910011690 S.COIL
L43 6910011690 S.COIL
L44 6910011690 S.COIL
L45 6910011690 S.COIL
L46 6910011690 S.COIL
L47 6910011690 S.COIL
L48 6910011690 S.COIL
L49 6910011690 S.COIL
L50 6910011690 S.COIL
L51 6910011690 S.COIL
L52 6200007680 S.COIL
L53 6200007680 S.COIL
5 - 8
DESCRIPTION
GN2011-Q (TX)
TA31136FN (D,EL)
TA78L05F (TE12R)
MB15A02PFV1-G-BND-ER
TA75S01F (TE85R)
TA78L05F (TE12R)
TA78L06F (TE12L)
2SC5337QS-T1
2SK1771 (TE85R)
2SC2712-GR (TE85R)
2SC2712-GR (TE85R)
2SC4226-T1 R25
2SC4703-T2 SF
2SC4226-T1 R25
2SB1182 TL Q
2SC4081 T106 R
2SK880-Y (TE85R)
DTA143ZUA T106
2SA1576A T106R
2SC4081 T106 R
1SS226 (TE85R)
1SV284 (TPH3)
1SV284 (TPH3)
1SV284 (TPH3)
1SV284 (TPH3)
1SS268 (TE85R)
1SS268 (TE85R)
FL-349A (70.00 MHz)
CFWLA455KGFA-B0
CFWLA455KEFA-B0
CR-729 (69.545 MHz)
CR-732 (12.800 MHz)
LQW2BHN10NJ01L
C6328A-22NG-A
C6328A-22NG-A
LQW2BHN22NJ01L
C6328A-22NG-A
C6328A-22NG-A
458DB-1011=P3
458DB-1011=P3
458DB-1011=P3
ELJND R10J 0.1U
ELJND R27J-F
ELJND R68JF 0.68U
LQW2BHN15NJ01L
LQW2BHN27NJ01L
LQW2BHN12NJ01L
LQW2BHN12NJ01L
LQW2BHN15NJ01L
LQW2BHN15NJ01L
LQW2BHN15NJ01L
LQW2BHN15NJ01L
ELJND R68JF 0.68U
LQW2BHN10NJ01L
ELJND R22J 0.22U
ELJND R33J 0.33U
LQW2BHN12NJ01L
ELJND R68JF 0.68U
BLM21PG221SN1
ACB1608M-600-T
ACB1608M-600-T
ACB1608M-600-T
ACB1608M-600-T
ACB1608M-600-T
ACB1608M-600-T
ACB1608M-600-T
ACB1608M-600-T
ACB1608M-600-T
ACB1608M-600-T
LQW2BHN12NJ01L
LQW2BHN12NJ01L
S.=Surface mount
