Icom IC-FR3000 Service Manual page 95

[LOGIC UNIT]
REF ORDER
NO. NO.
R128 7030003680 S.RESISTOR
R129 7030006480 S.RESISTOR
R130 7030003620 S.RESISTOR
R131 7030001430 S.RESISTOR
R137 7030003560 S.RESISTOR
R138 7030003560 S.RESISTOR
R139 7030003620 S.RESISTOR
R140 7030003560 S.RESISTOR
R141 7030003560 S.RESISTOR
R143 7030000410 S.RESISTOR
R144 7030000480 S.RESISTOR
R145 7030000410 S.RESISTOR
R148 7030003760 S.RESISTOR
R149 7030003450 S.RESISTOR
R150 7030003450 S.RESISTOR
R151 7030003280 S.RESISTOR
R153 7030003560 S.RESISTOR
R154 7030008350 S.RESISTOR
R155 7030003560 S.RESISTOR
R158 7030003460 S.RESISTOR
R159 7030003460 S.RESISTOR
R160 7030003460 S.RESISTOR
R162 7030003600 S.RESISTOR
R163 7030003800 S.RESISTOR
R164 7030003620 S.RESISTOR
R165 7030003690 S.RESISTOR
R166 7030003680 S.RESISTOR
R168 7030003400 S.RESISTOR
R169 7030003690 S.RESISTOR
R170 7030003680 S.RESISTOR
R171 7030003680 S.RESISTOR
R172 7030003680 S.RESISTOR
R175 7030003680 S.RESISTOR
R177 7030003640 S.RESISTOR
R179 7030003700 S.RESISTOR
R182 7030003680 S.RESISTOR
R183 7030003680 S.RESISTOR
R184 7030003440 S.RESISTOR
R185 7030003570 S.RESISTOR
R186 7030003570 S.RESISTOR
R187 7030003490 S.RESISTOR
R188 7030003490 S.RESISTOR
R189 7410001130 S.ARRAY
R190 7030003560 S.RESISTOR
R191 7030003560 S.RESISTOR
R192 7030003750 S.RESISTOR
R193 7030003760 S.RESISTOR
R194 7030003750 S.RESISTOR
R195 7030003640 S.RESISTOR
R196 7410001150 S.ARRAY
R197 7410001150 S.ARRAY
R198 7410001130 S.ARRAY
R199 7410001130 S.ARRAY
R200 7410001150 S.ARRAY
R201 7410001130 S.ARRAY
R202 7410001150 S.ARRAY
R203 7410001130 S.ARRAY
R204 7030003680 S.RESISTOR
R205 7030003680 S.RESISTOR
R206 7030003640 S.RESISTOR
R207 7030003420 S.RESISTOR
R208 7030003640 S.RESISTOR
R209 7030003640 S.RESISTOR
R210 7030003620 S.RESISTOR
R211 7030003440 S.RESISTOR
R212 7030003620 S.RESISTOR
R213 7030003640 S.RESISTOR
R214 7030003440 S.RESISTOR
R215 7030003440 S.RESISTOR
R216 7410001130 S.ARRAY
R217 7410001130 S.ARRAY
R218 7410001130 S.ARRAY
R219 7410001130 S.ARRAY
R220 7410001130 S.ARRAY
R221 7410001150 S.ARRAY
R222 7410001130 S.ARRAY
R223 7410001130 S.ARRAY
R224 7410001130 S.ARRAY
R225 7030003680 S.RESISTOR
R227 7030003640 S.RESISTOR
R228 7030003640 S.RESISTOR
R229 7030003640 S.RESISTOR
DESCRIPTION
ERJ3GEYJ 104 V (100 kΩ)
MCR100JZHJ 10 Ω (100)
ERJ3GEYJ 333 V (33 kΩ)
MCR50JZHJ 27 kΩ
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
MCR10EZHJ 1.8 kΩ
MCR10EZHJ 6.8 kΩ
MCR10EZHJ 1.8 kΩ
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ12YJ390U
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 124 V (120 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 124 V (120 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
EXB28V102JX
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 394 V (390 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 394 V (390 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
EXB28V471JX
EXB28V471JX
EXB28V102JX
EXB28V102JX
EXB28V471JX
EXB28V102JX
EXB28V471JX
EXB28V102JX
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
EXB28V102JX
EXB28V102JX
EXB28V102JX
EXB28V102JX
EXB28V102JX
EXB28V471JX
EXB28V102JX
EXB28V102JX
EXB28V102JX
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
[LOGIC UNIT]
REF ORDER
NO. NO.
R230 7030003640 S.RESISTOR
R231 7030003640 S.RESISTOR
R232 7030003640 S.RESISTOR
R233 7030003640 S.RESISTOR
R234 7030003640 S.RESISTOR
R235 7030003440 S.RESISTOR
R236 7030003440 S.RESISTOR
R237 7030003440 S.RESISTOR
R238 7030003440 S.RESISTOR
R239 7410001130 S.ARRAY
R240 7030003440 S.RESISTOR
R241 7030003200 S.RESISTOR
R242 7030003680 S.RESISTOR
R243 7030003680 S.RESISTOR
R245 7030003570 S.RESISTOR
R246 7410001140 S.ARRAY
R247 7030003680 S.RESISTOR
R250 7410001140 S.ARRAY
R251 7030003680 S.RESISTOR
R256 7030003240 S.RESISTOR
R257 7030003620 S.RESISTOR
R258 7030003650 S.RESISTOR
R259 7030003680 S.RESISTOR
R260 7030003680 S.RESISTOR
R261 7030003640 S.RESISTOR
R262 7030001210 S.RESISTOR
R263 7030003410 S.RESISTOR
R264 7030003410 S.RESISTOR
R265 7030003450 S.RESISTOR
R266 7030003440 S.RESISTOR
R268 7030003640 S.RESISTOR
R269 7030003680 S.RESISTOR
R275 7030003680 S.RESISTOR
R276 7030003560 S.RESISTOR
R277 7030003680 S.RESISTOR
R278 7030003680 S.RESISTOR
R279 7030003680 S.RESISTOR
R280 7030003680 S.RESISTOR
R281 7030003680 S.RESISTOR
R282 7030003740 S.RESISTOR
R283 7030003560 S.RESISTOR
R284 7030003700 S.RESISTOR
R285 7030003700 S.RESISTOR
R289 7030003660 S.RESISTOR
R290 7030003640 S.RESISTOR
R291 7030003660 S.RESISTOR
R292 7030003520 S.RESISTOR
R293 7030003670 S.RESISTOR
R294 7030003670 S.RESISTOR
R295 7030003650 S.RESISTOR
R297 7030003620 S.RESISTOR
R300 7030003520 S.RESISTOR
R304 7030003800 S.RESISTOR
R305 7030003620 S.RESISTOR
R306 7030003600 S.RESISTOR
R307 7030003410 S.RESISTOR
R312 7030003540 S.RESISTOR
R313 7030003680 S.RESISTOR
R314 7030003520 S.RESISTOR
R315 7030003680 S.RESISTOR
R316 7030003540 S.RESISTOR
R317 7030003680 S.RESISTOR
R318 7030003470 S.RESISTOR
R320 7030003640 S.RESISTOR
R321 7030003680 S.RESISTOR
R322 7030003540 S.RESISTOR
R323 7030003680 S.RESISTOR
R325 7030003680 S.RESISTOR
R326 7030003540 S.RESISTOR
R327 7030003680 S.RESISTOR
R328 7030003520 S.RESISTOR
R329 7030003680 S.RESISTOR
R330 7030003520 S.RESISTOR
R331 7030003520 S.RESISTOR
R332 7030003540 S.RESISTOR
R334 7030003520 S.RESISTOR
R335 7030003520 S.RESISTOR
R336 7030003680 S.RESISTOR
R337 7030003540 S.RESISTOR
R338 7030003200 S.RESISTOR
R339 7030003200 S.RESISTOR
R340 7030003200 S.RESISTOR
5 - 4
DESCRIPTION
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
EXB28V102JX
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
EXB28V104JX
ERJ3GEYJ 104 V (100 kΩ)
EXB28V104JX
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 220 V (22 Ω)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
MCR50JZHJ 470 Ω (471)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 100 V (10 Ω)
S.=Surface mount
