Icom IC-FR3000 Service Manual page 20
Vhf fm repeater
Hide thumbs
Also See for IC-FR3000:
- Sales handbook (74 pages) ,
- Instruction manual (24 pages) ,
- Remote control manual (14 pages)
Table of Contents
Advertisement
• IC-FR3000 TOP VIEW
• TX UNIT TOP VIEW
CP4
C17 (TVCO unit)
TX VCO lock voltage
adjustment
DC/REG UNITS
CP4
CP4
TX VCO lock voltage
check point
PA UNIT
• RX UNIT TOP VIEW
CP2
Reference frequency
check point
CP3
CP1
CP18
LV
CP3
RX VCO lock voltage
chack point
4 - 5
TX UNIT
RX UNIT
CP2
L10
CP2
C17 (RVCO unit)
RX VCO lock voltage
adjustment
