B-FOCuS 270/285/400 PR
2.

Preparatory Actions

2.1.

Required Infrastructure

To be connected to the router, the computer requires the following:
• CPU: At least 266MHz.
• An Ethernet Network Interface Card: Either 10Mbps or 100Mbps.
• Operating System: Windows 98, NT, ME, 2000 or XP, Unix or Macintosh.
• Browser: Internet Explorer, version 5.5 and above.
2.2.

Defining the Computer in the LAN

Prior to invoking the configuration software, the computer should be defined on the
same subnet with the router.
The access to the definition windows differs somewhat for the various operating
systems. The example presented here refers to Windows XP.
To redefine the computers in the Local Area Network (LAN):
1. From the Start menu, select Settings > Control Panel > Network Connections.
The Network Connections dialog box appears.
2. From the list of connections to networks, select the Network Interface Card you
used for connecting the computer to the router's eth0 port. The Local Area
Connection Status dialog box appears.
3. Click Properties. The Local Area Connection Properties dialog box appears.
