6.2.2. Advanced Workflow

To define a bridge per RFC 1483 in the advanced way:
1. You have to assign the interfaces you want to define to the bridging group. From
the Advanced operations menu select Bridging.
2. Click Flush.
3. In the Bridge tab, click GroupInfo. The Group Interfaces dialog box appears.
4. Check the interfaces you want to add to the group (in this example: etho, atm0,
atm1).
5. Click Apply. This line is added to the List of Bridge Entries.
6. To define the bridge, from the Advanced operations menu click Configure.
7. In the VCC tab click Add. The VCC Configuration dialog box appears. As a
default, the bridge definition radio button is selected. Enter the VCI and VPI
values. Select the service type. Define the traffic shaping parameters.
8. Click Apply. A line is added to the VCC table.
