6.2.

Defining a Bridge per RFC 1483

You can define a bridge in two ways. The basic workflow is simple, but most of the
parameters are defined by default. The advanced workflow enables detailed definition
of most parameters.

6.2.1. Basic Workflow

To define a bridge per RFC 1483 in the basic way:
1. From the Basic operations menu select WAN Setup. The WAN Setup dialog box
appears.
2. Click the RFC 1483 Bridged radio button.
3. In the top line enter the VPI and VCI values and select the LLC/SNAP radio
button.
4. At the bottom of the dialog box click Add.
5. Check that a new line, containing the values you have defined, is added to the
table at the bottom of the dialog box.
Note: When defining a bridge in the basic way, all the channels are opened by default
under the atm0 interface.
