Summary of Contents for Webasto Thermo Call TC2 COMFORT
-
Page 1: Einbau Mit Vorwahluhr
Einbauanweisung Installation Manual Instructions de montage Manuale di Installazione Инструкция по установке Instrukcja montażu Monteringsinstruktion Monteringsanvisning Inbouwinstructies Monteringsvejledning Návod na montáž Thermo Call TC2 COMFORT Thermo Call TC2 LOCATE 03/2008... -
Page 2: Endanschluss Und Test
Webasto training course and have the appropriate technical documentation, special tools and special equipment. NEVER try to install or repair Webasto heating or cooling systems if you have not completed a Webasto training course, you do not have the necessary technical skills and you do not have the technical documentation, tools and equipment available to ensure that you can complete the installation and repair work properly. -
Page 3: Table Of Contents
Thermo Call TC2 Inhaltsverzeichnis Table of Contents Table des matières Lieferumfang..........1 Delivery scope ..........9 Composition de la fourniture ..... 17 Einbau ............2 Installation............ 10 Montage............18 Einbau Thermo Call TC2 ......2 Installation of Thermo Call TC2 ....10 Montage du Thermo Call TC2.... -
Page 4: Technische Daten
Thermo Call TC2 Innholdsfortegnelse Innehållsförteckning Inhoudsopgave Leveringsomfang ......... 49 Leveransomfattning ........57 Leveringsomvang ........65 Montering............50 Montering ............. 58 Inbouw............66 Montering av Thermo Call TC2....50 Montering Thermo Call TC2...... 58 Inbouw Thermo Call TC2......66 Montering av GSM Antenne ...... 50 Montering GSM-antenn...... -
Page 5: Delivery Scope
Thermo Call TC2 Delivery scope Thermo Call TC2 main module SIM holder (upon delivery, already located within the card bay of the main module) GSM antenna (dual band) with FME plug Main cable harness Plastic bag with installation materials and items 6 to 9 Push-button switch with integrated LED Purple wire (summer / winter wire) Plug housing... -
Page 6: Installation
Thermo Call TC2 Installation Installation of Thermo Call Installation of GSM- Before starting the installation, insert the SIM card (included in the delivery), into the Antenna SIM holder after removing the holder from the main module by pressing the yellow Caution: The antenna must be fastened to the front button.The Sim card to be used must be... -
Page 7: Installation Of Gps Antenna (Tc2 Locate Only)
Thermo Call TC2 Installation of GPS antenna (TC2 LOCATE only) The antenna has to be mounted horizontally and covers over the antenna may not contain any metallic materials. - Clean the mounting place with the cleaning cloth that is included in the delivery. -
Page 8: Connection To Heaters
Thermo Call TC2 Connection to heaters Installation with Push- IMPORTANT: Red wire: The analog connections should be made To pin 3, directly opposite the red cable in Button as follows: the timer plug of the main cable harness The Push-Button included with the delivery - Insert the micro-timer of the purple Black wire: must be installed if no other operating... -
Page 9: Installation With Digital Timer
Please use the special Y-Adapter when installing Thermo Call at systems where Telestart is already installed (see Webasto accessory catalogue). This is additionally available as a Webasto original Timer accessory.Please also note the selection of... -
Page 10: Final Connection And Test
Thermo Call TC2 Final Connection and Test - Connect the enclosed short purple wire (3), using the connector (4), to the purple wire (5) of the additional heating cable harness. - Connect the 12-pin plug (1) of the main cable harness (2) to the main - Plug micro-timer (2) into free location module of the Thermo Call TC2 of the 4-pole connector (1) (digital... -
Page 11: Programming
Thermo Call TC2 Programming Programming the System Thermo Call TC2 can be programmed via mobile or fixed network telephones that Time feature tone dialing (DTMF). Deactivate W-BUS connection After programming via the technician (= factory setting). - Call Thermo Call TC2 with a fixed menu, the system time must still be set via network or mobile telephone the customer menu. -
Page 12: Technical Data
Thermo Call TC2 Technical data Thermo Call TC2 Comfort Thermo Call TC2 Locate Size L/W/H approx. 115 x 84 x 31 mm approx. 115 x 84 x 31 mm Frequency GSM 900/1800 MHz GSM 900/1800 MHz Power consumption (average) < 15 mA <... -
Page 13: Composition De La Fourniture
Dans le cas d'une version rédigée en plusieurs langues, l'allemand est alors la langue qui fait foi. Nel caso di una versione plurilingue il tedesco è vincolante. Webasto AG Для изданий на нескольких языках обязательным является немецкий вариант. Kraillinger Strasse 5 W przypadku wersji kilkujęzyčznej wiążący jest tekst w języku niemieckim.
