Internet Explorer - SMC Networks SMC7004ABR Quick Installation Manual

4. After writing down your IP settings, select "Using DHCP Server" in the "Configure" field
and close the window.
5. Another box will appear asking whether you want to save
your TCP/IP settings. Click Save.
TCP/IP Configuration Setting
IP Address
Subnet Mask
Router
Name Server
Step 2. Disable HTTP Proxy
You will need to verify that the "HTTP Proxy" feature of your Web browser is disabled. This is
so that your Web browser will be able to view the configuration pages inside your Barricade.
The following steps are for Internet Explorer and for Netscape. Determine which browser you
use and follow the appropriate steps.

Internet Explorer

1. Open Internet Explorer and click the stop button. Click "Edit" and select
"Preferences."
2. In the Internet Explorer Preferences window,
under Network, select Proxies.
3. Uncheck all checkboxes and click OK.
Page 18
____.____.____.____
____.____.____.____
____.____.____.____
____.____.____.____
