  • Page 1: Condensing Boiler

    MURELLE GREEN PLANET I-HE 35 MF & E-HE35 MF CONDENSING BOILER User, Service and Installation Instructions...

  • Page 2: Table Of Contents

    Warranty to beco me null and void. FONDERIE SIME S.p.A. of Via Garbo 27 - Legnago (VR) - Italy declares that its hot water boilers, which bear the CE mark under Gas Directive 90/396/CEE and are fitted with a safety thermostat calibrated to a maximum of 110° C, are not subject to application of PED Directive 97/23/CEE as they meet the requirements of article 1 paragraph 3.6 of the Directive.

  • Page 3: Users Instructions

    USER INSTRUCTIONS WARNINGS – In case of fault and/or incorrect equipment operation, deactivate it, without making any repairs or taking any direct action. Apply only to qualified technical personnel. – Boiler installation and any other assistance and/or maintenance activity must be carried out by qualified personnel registered as a licenced gas technician.
  • Page 4 REGULATION OF THE WATER TEMPERATURE FOR HEATING (fig. 25) To set the temperature of the water for heating, press the key of the controls (2). The first time the key is pressed, the SET of heating circuit 1 is selected. The second time it is pressed, the SET of heating circuit 2 is selected.
  • Page 5 ANOMALIES AND SOLUTIONS stance from qualified technical personnel. stance from qualified technical personnel. When there is a functioning anomaly, the display shows an alarm and the blue lumi- nous bar becomes red. Descriptions of the anomalies with the rela- tive alarms and solutions are given below: –...

  • Page 6: Users Pre-Service Check List

    2.0 USER’S PRE-SERVICE CHECK LIST I’m Cold – The Heaters not Working Before calling for Hunt Heating Boiler Service please check the following. 1 General. Has the system worked before? if it did why did it stop? Check that the power, gas, valves or thermostat are turned ON Does it work? - If NO go to Q2 2 Power With power to the boiler.

  • Page 7: Boiler Registration

    Installation A ddress - Street City State Installation Ph one N umber Contact and Ph one Nu mber Sime Product - Model Internal - I-HE 35 or External - E-HE 35 Serial Nu mber refer to data plate External Internal...

  • Page 8: Commissioning Boiler Check List

    4.0 COMMISSIONING BO ILER CH ECK LIST A s uggested me thod of co mmissioning th e bo iler, ac tual me thod ca n v ary ac cording t o th e bo iler make type and the installation. The boiler must always be installed and commissioned by an approved gas te chnician.

  • Page 9: Service Records

    Handover Ins tructions when d one Fill in al l th e de tails on t his Bo iler manua. l Instruct th e o wner /u sers on th e co rrect op eration of th e h eating s ystem, th is includes ho w t o tu rn th e sy stems o n a nd of f, ad just th e t ime an d t emperature settings .
  • Page 10 Service – 2 – year 3 Date Service te chnician Name PIC L icence No . Service Co mpany Contact ph one nu mber Work Co mpleted Notes Service – – year 5 Date : Service te chnician Name: PIC L icence No . Service Co mpany Contact ph one nu mber Work Co mpleted...
  • Page 11 Service – 5 – year 9 Date Service te chnician Name PIC L icence No . Service Co mpany Contact ph one nu mber Work Co mpleted Notes Service – – year 11 Date : Service te chnician Name: PIC L icence No . Service Co mpany Contact ph one nu mber Work Co mpleted...

  • Page 12: Installer Instructions

    6.0 INSTALLER INSTRUCTIONS CONTENTS DESCRIPTION OF THE BOILER ..............page INSTALLATION .

  • Page 13: Description Of The Boiler

    DHW using a calorifier or to control and manage all the functions. always follow the instructions provided in both functions. DIMENSIONS 1.2.1 MURELLE GREEN PLANET I-HE 35 MF - INTERNAL BOILER 92,5 42,5 85 70 70 70 70 Central Heating Return 3/4”...
  • Page 14 1.2.2 MURELLE GREEN PLANET E-HE 35 MF - EXTERNAL BOILER Apply gasket seal to rear of cabinet part no. A6229825 - 515 x 4 x 15 supplied 117,5 43,5 70 70 70 70 Central Heating Return 3/4” BSP MI NOTE M Central Heating Flow 3/4”...
  • Page 15 TECHNICAL FEATURES Model I-HE 35 MF & E-HE 35 MF Heat output - Gas pressures available Nominal (80-60°C) 34. 1 Nominal (50-30°C) 37.2 Reduced (80-60°C) Reduced (50-30°C) Heat input Nominal MJ/h 125.6 Reduced Nat/LPG 1 MJ/h 32.5 Losses after shutdown to 50°C (EN 483) V-Hz 240 /50 Supply voltage...
  • Page 16 FUNCTIONAL DIAGRAM - Schematic only All items shown in the grey area are not part of the standard boiler package but is included to illustrate the optional DHW heating capacity of this boiler. 1 Fan 24 Gas cock (optional) 3 Primary exchanger 25 C.H.
  • Page 17 MAIN COMPONENTS 10 Sensor fumes 1 Control panel 11 Suction/discharge fitting 2 Aqua Guard Filter System 12 Expansion vessel 3 Condensate drain tap 13 Detection electrode 4 Air pressure tap 14 Fan 5 Ignition transformer 15 Water flow meter Fig. 3 6 Safety thermostat 16 Diverter valve 7 C.H.

  • Page 18: Installation

    INSTALLATION The boiler must be installed in a fixed loca- CONNECTING UP SYSTEM – 1.0 mbar for family II gases (natural gas); tion and only by specialised and qualified – 2.0 mbar for family III gases (butane or firms in compliance with all instructions To protect the heat system from damaging propane).
  • Page 19 between 1 and 1.5 bar. Let off air acting on use the discharge valve (5 fig. 4). (B). the knob 21 fig. 4/a. - The kits with dedicated ø 60 pipes, code 8089913, include a suction collar that INSTALLATION OF replaces the boiler collar (C).
  • Page 20 ASSEMBLY OF THE KIT ø 80 code 8089912/ø 60 code 8089913 OPERATIONS REQUIRED ONLY FOR THE ASSEMBLY OPERAZIONE DA ESEGUIRE OF THE ø 80 KIT CODE SOLO NEL MONTAGGIO DEL KIT Ø 80 COD. 8089912 8089912 ø 108 Gasket CA CA ø...

  • Page 21: Important

    LIST OF ø 60 ACCESSORIES Coaxial duct kit code 8089913 Additional 90° MF curve code code 8089921 2 b MF 90° bend with suction tap, code 8089924 Extension L. 1000 code 8089920 4 Exhaust terminal, code 8089541 5 Kit with internal/external ring nuts, code 8091510 6 Suction terminal, code 8089540 Additional 45°...
  • Page 22 POSITIONING THE ELECTRICAL CONNECTION cing between contacts. OUTLET TERMINALS Respect the L and N polarities and the The outlet terminals for forced-draught The boiler is supplied with an electric cable. earth connection. appliances may be located in the external Should this require replacement, it must be perimeter walls of the building.
  • Page 23 2.8.1 Chronothermostat 2.8.3 Remote control CR73 matically regulate the temperature value of connection connection (optional) the boiler output according to the external temperature. Connect the chronothermostat as indica- The boiler is designed for connection to a For installation, follow the instruction in the ted in the boiler electrical diagram (see fig.
  • Page 24 BOILER ELECTRICAL “I-HE 35 MF & E-HE 35 MF” EXP (24 VRAC) OP (24 VAC) (24 VRAC) (24 VRAC) (5 VDC) (24 VDC) (5 VDC) (5 VDC) (5 VDC) (5 VDC) (24 VRAC) Zone 1 environment thermostat CONNECTOR SPARE PART CODES: F1-2 Fuse (4 AT) Zone 2 environment thermostat...

  • Page 25: Characteristics

    CHARACTERISTICS CONTROL PANEL DESCRIPTION OF DISPLAY ICONS SUMMER MODE ICON WINTER MODE ICON D.H.W. MODE ICON HEATING MODE ICON 1 = First circuit heating system 2 = Second circuit heating system GRADED POWER SCALE The segments of the bar light up in proportion to boiler power output .
  • Page 26 ACCESS TO INSTALLER'S INFORMATION For access to information for the installer, press the key (3 fig. 14). Every time the key is pressed, the display moves to the next item of information. If the key is not pressed, the system automatically quits the function. List of information: 1.
  • Page 27 17. Visualizzazione portata sanitaria flussimetro (es. 18 l/min 17. Indication of D.H.W. flowmeter load (i.e. 18 l/min and 0.3 l/min) or flow 25. Indicator of pump with board Mixed Zone 2 25. Visualizzazione pompa con schedino ZONA MIX 2 e 0,3 l/min) o stato flussostato (rispettivamente ON e OFF) (rispettivamente ON e OFF) switch (respectively ON and OFF) (respectively ON and OFF)
  • Page 28 ACCESS TO PARAMETERS INSTALLER INSTALLER'S PARAMETERS FAST CONFIGURATION For access to the installer's parameters, press simultaneously the keys PAR DESCRIPTION RANGE UNIT OF INC/DEC DEFAULT or 5 seconds (3 fig. 12). MEASUREMENT UNIT SETTING For example, the parameter PAR 23 is Combustion configuration -- = ND “--”...
  • Page 29 BOILER PAR 2 PARAMETERS INSTALLER Instantaneous boiler with diverter valve microswitch and flow switch EXPANSION CARD Instantaneous boiler with diverter valve microswitch, PAR DESCRIPTION RANGE UNIT OF INC/DEC DEFAULT MEASUREMENT UNIT SETTING flow switch and solar combining Number of expansion boards 0 ...
  • Page 30 EXTERNAL SENSOR If there is an external sensor, the hea- ting settings SET can be taken from the climatic curves according to the exter- nal temperature and, in any case, limi- ted to with the range values described in point 3.3 (parameters PAR 25 for zone 1 and PAR 26 for zone 2).

  • Page 31: Important

    WATER FLOW SWITCH N.B. on system boilers it is important graph in fig. 14. that if the flow switch assembly is chan- The speed of the modulating pump is set The water flow gauge (15 fig. 3) intervenes, ged, it is fitted with the arrow pointing in as default (installation parameter blocking burner functioning, if it detects the correct direction.

  • Page 32: Use And Maintenance

    USE AND MAINTENANCE GAS VALVE The boiler is supplied as standard with a gas valve, model SIT 848 SIGMA (Fig. 16). Fig. 17 Upstream pressure intake Intermediate pressure intake Air signal inlet (VENT) Downstream pressure intake To change the fuel to propane (G31), it is 4.2.2 Calibrating the gas valve Capacity step...

  • Page 33: Important

    During maintenance operations, it is using the tap provided (fig. 20). Code 8106380 Model MURELLE GREEN PLANET I-HE 35 MF Serial n. 9999999999 PAR 1 = 24 (NG) / 25 (LPG) PAR 2 = 4...
  • Page 34 CONTROL PANEL CONDENSATE TRAP Fig. 20 Chimney sweep function (fig. 21) 4.5.1 To check boiler combustion, press the installer's key for a few seconds. The chimney sweep function will switch on and will continue for 15 minutes. From that moment, the boiler will start working in heating mode at maximum power, with cut off at 80°C and re-ignition at 70°C (ATTENTION! Temperature may...
  • Page 35 [TVw] [Tag A + B Flow temperature setpoint Period in days Start day Functional heating Fig. 22/a Floor curing heating Fig. 23/a Page 35 of 40...
  • Page 36 – HIGH WATER PRESSURE ANOMALY ALARM 03 (fig. 23/b) If the pressure detected by the transdu- cer is more than 2.8 bar, the boiler stops and the display shows anomaly “ALL 03" Fig. 23/b – D.H.W. SENSOR ANOMALY ALARM 04 (fig. 23/c) If the D.H.W.
  • Page 37 – FLAME DETECTION BOILER COMBINED WITH SUN-PANEL pump, the mixed zone valve closes and ERROR 08 (fig. 23/g) SYSTEM: anomaly of the D.H.W. input the display indicates error ALL 20. If the flame control detects aflame when sensor. When the sensor is open or During this this error the boiler functions one should not be detected, the boiler short circuited, the boiler loses the sun-...
  • Page 38 the boiler functions normally. – SOLAR APPLICATION CONFIGURATION “ALL 27” (fig. 23/w) When the solar board is connected to the boiler. If the hydraulic configuration of the boiler is incorrect (PAR2), the display indicates error ALL 27. During this error the boiler continues to function normally, and only the antifreeze function on the solar board is active.
  • Page 39 Page 39 of 40...
  • Page 40 HUNT HEATING HYDRONIC SYSTEMS (Australia) Pty. Ltd. 11 Fiveways Boulevard, Keysborough, Victoria 3173 Telephone 1300 00 1800 Facsimile 9798 5133 www.huntheat.com.au...
