Sime PLANET DEWY 30 BF Installer's Instructions

Hide thumbs Also See for PLANET DEWY 30 BF:

Advertisement

Quick Links

Download this manual See also: Instructions for Using

INSTALLER INSTRUCTIONS

CONTENTS
1
DESCRIPTION OF THE BOILER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 88
2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 91
3
CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 101
4
USE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pag. 104
When carrying out commissioning of the boiler, you are highly recommended to perform the following checks:
– Make sure that there are no liquids or inflammable materials in the immediate vicinity of the boiler.
– Make sure that the electrical connections have been made correctly and that the earth wire is connected to a
good earthing system.
– Open the gas tap and check the soundness of the connections, including that of the burner.
– Make sure that the boiler is set for operation for the type of gas supplied.
– Check that the flue pipe for the outlet of the products of the combustion is unobstructed and has been properly
installed.
– Make sure that any shutoff valves are open.
– Make sure that the system is charged with water and is thoroughly vented.
– Check that the circulating pump is not locked (CAUTION: Remember to release the pump coupled with the control
panel, if necessary, to protect the electronic control card).
– Purge the system, bleeding off the air present in the gas pipe by operating the pressure relief valve on the gas
valve inlet.
– Check that the syphened drip is fully filled with water. If necessary, fill it via the special opening.
FONDERIE SIME S.p.A. of Via Garbo 27 - Legnago (VR) - Italy declares that its hot water boilers, which bear the CE
mark under Gas Directive 90/396/CEE and are fitted with a safety thermostat calibrated to a maximum of 110°C,
are not subject to application of PED Directive 97/23/CEE as they meet the requirements of article 1 paragraph
3.6 of the Directive.
IMPORTANT

Advertisement

loading
Need help?

Need help?

Do you have a question about the PLANET DEWY 30 BF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sime PLANET DEWY 30 BF

Summary of Contents for Sime PLANET DEWY 30 BF

  • Page 1: Installer Instructions

    – Check that the syphened drip is fully filled with water. If necessary, fill it via the special opening. FONDERIE SIME S.p.A. of Via Garbo 27 - Legnago (VR) - Italy declares that its hot water boilers, which bear the CE mark under Gas Directive 90/396/CEE and are fitted with a safety thermostat calibrated to a maximum of 110°C,...

  • Page 2: Description Of The Boiler

    DESCRIPTION OF THE BOILER 1. 1 INTRODUCTION microprocessor technology for function - EN 625. They may be fuelled by natural gas control and management. They comply with (methane gas) or propane (G31). “PLANET DEWY 30/50 BF” with stainless the european directives 90/396/CEE, The instructions given in this manual are steel hot water tank, boilers are premix con- 89/336/CEE, 73/23/CEE, 92/42/CEE...
  • Page 3 TECHNICAL FEATURES 30 BF Heat output nominal (80-60°C) kW (kcal/h) 29.2 (25, 1 12) Heat output nominal (50-30°C) kW (kcal/h) 32.2 (27,690) Heat output minimum (80-60°C) kW (kcal/h) 7.6 (6,540) Heat output minimum(50-30°C) kW (kcal/h) 8.4 (7,220) Nominal heat output kW (kcal/h) 30.0 (25,800) Minimum heat output...
  • Page 4 FUNCTIONAL DIAGRAM LEGEND 1 Fan 2 Air/gas mixer 3 Primary exchanger 4 Gas valve 5 50 litre hot water tank 6 Heating probe (SM) 7 100°C safety thermostat 8 Air bleed valve 9 Heating system circulator 10 Hot water circulator 11 Heating expansion tank 12 Hot water safety valve 13 Heating system safety valve...
  • Page 5 INSTALLATION The boiler must be installed in a fixed loca- tion and only by specialized and qualified firms in compliance with all instructions contained in this manual. Furthermore, the installation must be in accordance with current standards and regulations. 2. 1 BOILER ROOM The boilers can be installed in any domestic environment without any location restric-...
  • Page 6 When you have finished filling the system close the fill cock. 1a-b Coaxial duct kit code 8096250 Extension L. 1000 code 8096150 Extension L. 500 code 8096151 COAXIAL DUCT ø 60/100 Vertical extension L. 140 with take-off point code 8086950 90°...
  • Page 7 TABLE 2 2.7. 1 Separate pipe accessories Accessories ø 80 Total head loss (mm H Kit code 8089911 is supplied for this pur- “PLANET DEWY 30/50 BF” model pose (fig. 10). Inlet Outlet Roof outlet A complete range of accessories to meet all 90°...
  • Page 8 2.7.3 Separate-pipes roof outlet There is the possibility of doubling the air- maximum rectilinear development intake and smoke-outlet pipes and then brin- allowed for the pipes must not exceed The accessories to be used for this type of ging them back together again so as to 13 mm H installation and some of the connecting obtain a concentric discharge by using the...
  • Page 9 The boiler is supplied with an electric cable. To provide some indications of possible solu- Should this require replacement, it must be NOTE: SIME declines all responsibility for tions, Table 1 gives the minimum distances purchased exclusively from SIME. injury or damage to persons, animals or...
  • Page 10 things, resulting from the failure to provi- 2. 1 0.2 “Logica Remote Control” A telephone remote switch with a zero de for proper earthing of the appliance. connection (fig. 15 pos. B) potential contact or a window contact can be connected to terminals 3-4. The electrical plant must comply with local Equipment for the checking of civil plants 2.
  • Page 11 2. 1 0.4 Wiring diagram EV1 Gas valve coil Logica Remote Control (optional cod. 8092204) EV2 Gas valve coil Ventilator board Ignition electrode Time programmer Sensing electrode Smoke stat 100°C safety stat Heating system pump TPA Water pressure transducer Note: The room stat (TA) must be connected to the Heating system pump terminals 5-6 External sensor (optional cod.
  • Page 12 2. 1 1 LOGICA REMOTE CONTROL vious day. ne system with external contact or – Holiday programme: the programme is through a window contact. All the boiler's functions can be managed interrupted for the holiday period and – Anti-bacterial. by a optional digital multifunctional device automatically restarted on returning code 8092204 for the remote of the boi- home.
  • Page 13 Maximum limit of delivery The delivery temperature is limited to the maximum set value. temperature Variation of the maximum speed of the The increase per minute of the prescribed delivery temperature value sent delivery temperature in °C is limited to the imposed value. Activation of adaptation With the activation of the adaptation, the pre-set value transmitted to the boiler regulator is adapted to the effective heat need.
  • Page 14 Input function terminal 3-4 The freely programmable input (terminals 3-4) allows three different functions to be activated. The parameter has the following significance: 1 = If an external sensor is connected, the display will show the temperature of the external sensor ( _ _ = no sensor connected, function disabled). 2 = With an external contact, it is possible to switch-over to "reduced pre- set value of the ambient temperature".
  • Page 15 CHARACTERISTICS 3. 1 ELECTRONIC BOARD – “POT. ACC.” trimmer (6 fig. 19) set itself for about 1 minute at the mini- Trimmer to vary the pressure level upon mum modulation pressure, and will then The electronic boards are manufactured in ignition (STEP), of the gas valve.
  • Page 16 1 Ignition electrode earth faston 3 Fuse (1,6 AT) 4 Fuse(0, 1 6 AT) 5 “ANN. RIT.” connector 6 “POT. ACC.” trimmer 7 Conector “MET-GPL” 8 D.H.W. potentiometer 9 Detector electrode faston 10 “POT. RISC.” trimmer 11 C.H. potentiometer 12 Selector CR/OFF/EST/INV/RESET 13 DIP SWITCH 14 Connector “Modureg Sel.”...
  • Page 17 This may occur upon first ignition or after long periods of boiler lay-off when there is air in the pipes. It may be caused by the gas cock being closed or by one of the valve coils having a break in the win- ding, so that the valve cannot open.

  • Page 18: Use And Maintenance

    USE AND MAINTENANCE 4. 1 D.H.W. PRODUCTION The preparation of hot water is guaranteed by the glass storage tank unit with magne- sium anode for the protection of the boiler unit and inspection flange for its control and cleaning. The magnesium anode must be checked annually and substituted when it is worn.
  • Page 19 BOILER CALIBRATION GAS CONVERSION connections using soapy water or appropriate products. DO NOT USE NAKED FLAMES. – Close the gas cock. – Stick onto the casing panel the – Replace the injector (pos. 30) plate showing the relevant fee- and the relevant gasket (pos. ding gas.
  • Page 20 DISASSEMBLY OF efficient operation of equipment and safety water functioning. To do so it is enough, EXPANSION VESSEL devices must be carried out exclusively by after having activated the chimney sweep authorized technical personnel. function, to take some hot water from one To disassemble the expansion vessel, pro- or more taps;...

  • Page 21: User Instructions

    USER INSTRUCTIONS WARNINGS – In case of fault and/or incorrect equipment operation, deactivate it, without making any repairs or taking any direct action. Contact an authorised technical staff. – The installation of the boiler and any servicing or maintenance job must be carried out by qualified personnel. Under no circumstances, the devices sealed by the manufacturer can be tampered with.
  • Page 22 due to the freezing of the water. for which the boiler has been equipped, the efficient operation of the equipment approach the technical staff. and safety devices must be carried out exclusively by the authorized technical GAS CONVERSION staff. The boiler is supplied with an elec- CLEANING AND MAINTENANCE tric cable.

  • Page 23: Logica Remote Control

    – Safety stat trip (fig. 5) If the safety thermostat trips, the red FLASHING RED LED SPIA ROSSA INTERMITTENTE "35°C" led will start flashing. In order to attempt a boiler restar t, rotate the selector knob to position ( ) and relea- se immediately, returning it to the sum- mer ( ) or winter (...
  • Page 24 ACTIVATING During functioning the lid of the regulator must be closed. – Selection of the operating mode The operating mode desired is selected by (reference keys grey colour) pressing the relative key with the correspon- ding symbol. The choice is displayed with the symbol Automatic functioning: the heating functions automatically according to the hea- ting programme entered.
  • Page 25 – On-line key If the rooms remain unused for a long period of time, the temperatu- re can be reduced with the on-line key, in this way saving energy. When the rooms are occupied again, press the on-line key to re-heat them. The current choice is displayed on the display: Fixed temperature heating Reduced temperature heating...
  • Page 26 – Heating/hot-water With the heating programme it is possible to set the switching times of the temperature for a service programme period of a week. The weekly programme consists of 7 daily programmes. One daily program- me allows 3 phases of heating. Each phase is defined by a starting time and a finishing time. The n.
  • Page 27 – Setting the time To set the current day of the week (1 = Monday/7 = Sunday) To set the current hour To set the current minute Once the hour is completed, the setting of the hour changes. With keys the current hour is regulated. Pressing these keys together, the regulation is speeded up in an increasing sense.
  • Page 28 – Error display Ignition lock-out Rotate selector CR/OFF/EST/INV/RESET on the boiler control panel to the release position ) to reset operation (fig. 3). If the lock-out re-occurs, call an authorised Service Centre. Safety thermostat trip Rotate selector CR/OFF/EST/INV/RESET on the boiler control panel to the release position ) to reset operation (fig.
  • Page 29 *Caldaie a basse emissioni inquinanti (“classe 5” rispetto alle norme europee UNI EN 297 e EN 483). Legnago, 29 luglio 2005 Il Direttore Generale ing. Aldo Gava Fonderie Sime S.p.A. - Via Garbo, 27 - 37045 Legnago (Vr) - Tel. 0442 631111 - Fax Servizio Tecnico 0442 631292 - www.sime.it...
  • Page 30 31,6 86,9 93,5 84,4 92,0 PLANET DEWY 25 BF - 25 BFT 24,0 24,9 92,4 96,6 98,4 106,2 PLANET DEWY 30 BF - 30 BFT 29,3 30,0 92,5 97,7 98,5 106,6 PLANET DEWY 30 BFR 28,3 29,0 92,5 97,7 98,5...
  • Page 32 Fonderie Sime S.p.A - Via Garbo, 27 - 37045 Legnago (Vr) Tel. + 39 0442 631111 - Fax +39 0442 631292 - www.sime.it...
