Fronius IG Plus
3.0-1 / 3.8-1 / 5.0-1 / 6.0-1 / 7.5-1
10.0-1 / 11.4-1 / 11.4-3 / 12.0-3
42,0426,0071,EA 042008
USA
Operating Instructions
Inverter for grid-connected photo-
voltaic systems
