Appendix A: Specifications
Physical Description
Overall Dimensions
16.0" x 16.2" x 0.80"
406mm x 412mm x 20mm

Power Requirements

300 mA at +12VDC with +/-.5% regulation or better and 100 mA at -12VDC with +/-5%
regulation or better.

Optional Power Supplies

U.S.A. 102V to 132V; 58Hz to 62Hz; NEMA 5-15P plug
International 197V to 264V; 48Hz to 52Hz; I.E.C. Universal power receptacle
Japan 90V to 110V; 42Hz to 62Hz; NEMA 1-15P plug

Material and Cosmetics

Color: Pearl white
Finish: Matte (silk-like)
Material: Cycolac KJW flame-retardant ABS plastic

Operating Specifications

A Bit Pad Two performs to the specifications listed below. The word typical is used to
describe accuracy and proximity. Typical means the unit performs to that specification of
more than 90% of the active area at 25 degrees Celsius. A slight degradation occurs at the
extreme edges and corners of the active area.
The following specifications are provided to aid in the understanding and use of the
product.
Active Area (nominal)
11" x 11"
280mm x 280mm
Bit Pad Two 40
Weight
Maximum: 7 pounds
3.2kg
