The data tablet will respond to other commands, such as a command to change the
resolution, while it is on standby. If the Reset command is issued while the data tablet is on
standby, the data tablet honors the Reset command, but does not retract the XOFF state.

Reset

Command:
Use the Reset command to return the operating characteristics to their current switch
settings.
The factory-set defaults are:
Report Mode = Stream
Coordinate System = Absolute
Report Rate = 100 rps
Increment = 0
Resolution = 200 lpi
After a Reset is issued, there is a 10 millisecond delay before the Bit Pad Two is ready to
receive information from the host.

NOP (No Operation)

Command:
The data tablet performs no operation (NOP) when one of these commands is issued to it.
This function can be used as a pad between command sequences, e.g. between XON and
XOFF.
Switch Setting:
Switch Setting:
Bit Pad Two 28
