  • Page 1: Table Of Contents

    Bit Pad Two 1 Table of Contents Chapter 1 Operation Overview Chapter 2 Configuration Parameters Section A: Proximity Transmission Section B: Remote Control Section C: Baud Rate Section D: CTS Handshaking Section E: Hardware Interface Connector Pin Assignments Signal Levels Section F: Report Format and Cursor Output Codes Bit Pad Two Packed Binary Format Bit Pad ASCII BCD Format...

  • Page 2: Bit Pad Two

    Bit Pad Two 2 Reset NOP (No Operation) Checking the Data Tablet Chapter 5 Section A: Self-Test Diagnostic Function Section B: In Case of Failure Operating Environment, Installation, Care and Service Chapter 6 Section A: Operating Environment Temperature and Humidity Power Section B: Unpacking and Installation Unpacking...

  • Page 3: Chapter 1: Operation Overview

    Bit Pad Two 3 Chapter 1: Operation Overview The Bit Pad Two is a data tablet that acts as an input device. It allows for the translation of graphic information into digital, suitable for a digital device such as a computer. The Bit Pad Two is valuable in many applications, including: Steering a cursor on a computer terminal.
  • Page 4 Bit Pad Two 4 Power Supply: Source of power for the Bit Pad Two. It attaches to the data/power cable and the power line. Adapter Cables: Cable assemblies that can change the gender of the data/power cable connector; reverse the communication lines or convert the power supply plug to the international standards.
  • Page 5 Bit Pad Two 5 Reports are in counts of resolution, expressed as absolute coordinates or relative coordinates. Resolution: Smallest distance or movement that the data tablet can distinguish. Resolution is a measure of precision and is expressed in lines per inch (lpi) or lines per millimeter (lpmm).

  • Page 6: Chapter 2: Configuration Parameters

    Bit Pad Two 6 data tablet is in Absolute Mode. Reports are in relative coordinates when the data tablet is in Relative Mode. Absolute and Relative modes are two of the Bit Pad Two’s many operating characteristics. Other operating characteristics govern when reports are issued; how fast they are issued and the tablet resolution.

  • Page 7: Section B: Remote Control

    Bit Pad Two 7 to report the proximity status. Reports in the ASCII BCD format use the cursor/stylus flag character to identify an out-of-prox report. Section B: Remote Control The data tablet can be configured to accept or reject commands from the host. When the remote control is enabled, the data tablet is receptive to commands from the host.

  • Page 8: Section E: Hardware Interface

    Bit Pad Two 8 If the switch is set to enable CTS handshaking, the data tablet awaits CTS from the host before it can issue reports. If CTS is not asserted, the data tablet is inhibited from sending reports. If the switch is set to disable CTS handshaking, the data tablet ignores the CTS line. Section E: Hardware Interface The Bit Pad Two has an RS-232C interface.

  • Page 9: Signal Levels

    Bit Pad Two 9 An adapter cable is available to change the connector gender from female to male. Also, a reversing cable is available to reverse the communications lines; its pin assignments appear below: RS-232C Reversing Cable – Pin Assignments for the 25-Pin D Connector Signal Levels The table below specifies the signal levels for data transmissions: RS-232C Signal Levels...

  • Page 10: Section F: Report Format And Cursor Output Codes

    Bit Pad Two 10 Section F: Report Format and Cursor Output Codes Two report formats are available: packed binary and ASCII BCD. NOTE: To users of other Summagraphics data tablets or digitizers: the formats described here are specific to the Bit Pad Two and Bit Pad One. Other Summagraphics products have similarly named formats, but their content may be different.
  • Page 11 Bit Pad Two 11 Least significant bit Most significant bit Proximity, 0 when in proximity and 1 when out-of-prox Flag bit, identifying the stylus or cursor buttons being pressed. The cursor output codes are switch selective: *On the 3-button cursor, the buttons are distinguished by raised dimples, rather than by numbered labels.

  • Page 12: Bit Pad Ascii Bcd Format

    Bit Pad Two 12 Phasing bit, which is always 1 Parity bit One or two stop bits X0 to X11 X and Y coordinate bits. Y0 to Y11 NOTE: In Relative Mode, X11 and Y11 are the sign bits. The bit is 0 for a positive coordinate and 1 for a negative coordinate.

  • Page 13: Chapter 3: Guidelines For Writing A Software Driver

    Bit Pad Two 13 *On the 3-button cursor, the buttons are distinguished by raised dimples, rather than by numbered labels. In the table above, 1 corresponds to one dimple, 2 to two dimples and etc. <CR> ASCII carriage return <LF> ASCII line feed Chapter 3: Guidelines for Writing a Software Driver A computer must have a driver in order for the Bit Pad Two to be connected.
  • Page 14 Bit Pad Two 14 General Flowchart for Master Program to Read and Process Data Tablet Reports...
  • Page 15 Bit Pad Two 15 Detail A: Get and Decode Reports Subroutine...
  • Page 16 Bit Pad Two 16 Detail B: Data Input Subroutine...

  • Page 17: Chapter 4: Operating Characteristics And Commands

    Bit Pad Two 17 Chapter 4: Operating Characteristics and Commands Bit Pad Two has a variety of operating characteristics and functions. The operating characteristics control the report flow, report content and tablet resolution. Set the Bit Pad Two’s operating characteristics or initiate the functions with commands from the host or with the switches inside the tablet.

  • Page 18: Section A: Controlling The Report Flow And Content

    Bit Pad Two 18 Each characteristic or function and its commands are defined. For easy reference, the commands appear in ASCII and hexadecimal. Appendix B ASCII Conversion Chart also provides the binary, decimal and octal conversions. A summary of the commands and switch settings appears in Appendix D Quick Reference Sheet.
  • Page 19 Bit Pad Two 19 Switch Setting: Report Rate: DIP #1 Stream Mode: Switch Stream Mode: Please note that one command sets both the mode and Report Rate. However, five switches must be set to accomplish the same setting, two for the mode and three for the Report Rate.
  • Page 20 Bit Pad Two 20 Report Rate The Report Rate is the number of reports the data tablet issues each second. Use it with Stream or Switch Stream modes. Note that the Report Rate settings, such as 2 rps or 70 rps, are approximations.

  • Page 21: Point Mode

    Bit Pad Two 21 Point Mode Command: Switch Setting: In Point Mode, the Bit Pad Two issues one report each time a cursor or stylus button is pressed. Reports can be issued up to the maximum Report Rate available for the set baud rate.

  • Page 22: Relative Mode

    Bit Pad Two 22 In Absolute Mode, the Bit Pad Two issues reports as absolute coordinates. Absolute coordinates are measured relative to the tablet origin. Reports issued from out-of-prox are repeats of the last valid coordinate pair. NOTE: When reports are in binary format and the data tablet is in Absolute Mode, the maximum reportable value is 4095.

  • Page 23: Increment Mode

    Bit Pad Two 23 The effect is a restriction of the maximum delta between reported points. The delta is the distance from the last report to the current one. The maximum delta varies, depending on the tablet’s resolution setting. This relationship is quantified in the table below: Increment Mode Command: Switch Setting:...
  • Page 24 Bit Pad Two 24 Here’s a description of how Increment Mode works: last report issued becomes the center of an imaginary square whose sides are twice the increment value. The cursor can move anywhere inside the imaginary square without a report being issued. As soon as the increment is satisfied along either axis, the Bit Pad Two transmits the actual X and Y coordinates of the point.

  • Page 25: Section B: Combining Characteristics

    Bit Pad Two 25 (30,7) The increment is satisfied from the last point along the X axis only; the Bit Pad Two issues the new report. (32,17) The increment is satisfied from the last point along the Y axis only; the Bit Pad Two issues the new report.

  • Page 26: Section C: Other Commands

    Bit Pad Two 26 When the data tablet is in Remote Request and Increment modes, regardless of  whether the increment has been satisfied or not, the actual position where the stylus or cursor is when the data tablet receives the remote trigger is reported position.

  • Page 27: Resolution Send Configuration

    Bit Pad Two 27 Send Configuration Command: Switch Setting: Use the Send Configuration command to send a report to the host that identifies the data tablet model and its version of software. The output looks like this: MM1103_BIT_PAD_II_by_Summagraphics_Version_n.n<CR><LF> The underlines are spaces; n.n is the version number and the line feed is switch-selective. Transmission Control Command: Switch Setting:...

  • Page 28: Reset

    Bit Pad Two 28 The data tablet will respond to other commands, such as a command to change the resolution, while it is on standby. If the Reset command is issued while the data tablet is on standby, the data tablet honors the Reset command, but does not retract the XOFF state. Reset Command: Switch Setting:...

  • Page 29: Checking The Data Tablet

    Bit Pad Two 29 Chapter 5: Checking the Data Tablet A convenient functional check of the data tablet can be performed by connecting Bit Pad Two to a terminal and moving the cursor or stylus across the tablet’s active area. (The output is easier to interpret if you have the report format set for ASCII BCD.) The X and Y values should increase as the cursor or stylus slides from the tablet origin toward the end of the axis.

  • Page 30: Section A: Self-Test Diagnostic Function

    Bit Pad Two 30 Section A: Self-Test Diagnostic Function Command: Switch Setting: Use the Self-Test command to perform tests on the tablet and cursor or stylus. Self-Test checks: Analog circuitry  Cursor or stylus connection, operation and location  Digital circuitry ...

  • Page 31: Section B: In Case Of Failure

    Bit Pad Two 31 If the Self-Test output byte is an ASCII O or G, the data tablet passed the diagnostic tests. (An O simply indicates that the stylus/cursor is in proximity. A G indicates that it is out-of- prox.) Section B: In Case of Failure If the Bit Pad Two does not operate or fails the Self-Test, follow these steps: 1.

  • Page 32: Power

    5. Keep the shipment in its original container until an inspection is made by the carrier. 6. Notify GTCO CalComp by Turning Technologies at 1.866.746.3015 or email us at gtco.support@gtcocalcomp.com. Otherwise, unpack the Bit Pad Two. The package should include: Tablet with data/power cable attached ...

  • Page 33: Installation

    Bit Pad Two 33 Installation A brief summary of the steps for assembling and installing a Bit Pad Two is as follows: 1. Configure Bit Pad Two data tablet. 2. Adjust the tilt or use flat 3. Attach stylus holder, if applicable.

  • Page 34: Changing The Stylus Refill

    Bit Pad Two 34...
  • Page 35 Bit Pad Two 35 1. Configure Bit Pad Two Data Tablet The Bit Pad Two’s configuration parameters are set at the factory to your specifications. If however, you want to adjust the configuration, you can do so by setting the switches inside the tablet. It is advantageous to do this step before connecting the unit with the host since it requires disassembling the tablet.
  • Page 36 Bit Pad Two 36 The ON and OFF positions are labeled on each switch. Set a slide switch by sliding it to the desired position. Set a rocker switch by pressing down on the side next to the desired position. Use a pointed instrument. Do NOT, however, use a pencil or another instrument that could deposit residue, e.g.
  • Page 37 Bit Pad Two 37 Lift the tilt mounting gently to clear the cursor/stylus socket. Remove the tilt  assembly. Remove the paper backing from the rubber feet. Stick the feet on the tablet  back, approximately one inch from each corner. 3.
  • Page 38 If the system requires them, adapter cables are available to change the connector gender from female to male; or to reverse communication lines. Install an adapter cable between Bit Pad Two data/power cable and the host. 6. Connect the Tablet to the Power Source Plug the four-pin connector of the pigtail cable into the power supply.

  • Page 39: Section C: Fcc Considerations

    Number from GTCO CalComp by Turning Technologies Customer Support. When contacting Customer Support, please have ready the tablet serial number purchase order number. NOTE: Do not ship any equipment to GTCO CalComp by Turning Technologies without a Return Authorization Number.

  • Page 40: Specifications

    Bit Pad Two 40 Appendix A: Specifications Physical Description Overall Dimensions Active Area (nominal) Weight 16.0” x 16.2” x 0.80” 11” x 11” Maximum: 7 pounds 406mm x 412mm x 20mm 280mm x 280mm 3.2kg Power Requirements 300 mA at +12VDC with +/-.5% regulation or better and 100 mA at -12VDC with +/-5% regulation or better.
  • Page 41 Bit Pad Two 41 Accuracy The similarity of a distance measured by the tablet with the actual distance. Cursor Eccentricity How much the electrical center varies from the crosshair center as the cursor is rotated through 360 degrees. Jitter Repeatability error of short duration caused by electrical noise. Proximity Greatest distance above the drawing area that the pointing tool can be raised and still be sensed by the tablet.

  • Page 42: Appendix Bascii Conversion Chart

    Bit Pad Two 42 Appendix B: ASCII Conversion Chart...
  • Page 43 Bit Pad Two 43...
  • Page 44 Bit Pad Two 44...

  • Page 45: Appendix C How The Bit Pad Two Is Different From Bit Pad One

    Bit Pad Two 45 Appendix C: How the Bit Pad Two is Different from Bit Pad One Bit Pad Two is a second generation data tablet. It is, with some minor exceptions, a plug replacement for Bit Pad One. As an improved version of its predecessor, dissimilarities do exist.

  • Page 46: Appendix D Quick Reference Sheet Of Commands And Switch Settings

    Bit Pad Two 46 Switch Settings: DIP Switch 1...
  • Page 47 Bit Pad Two 47 Switch Settings: DIP Switch 3...
  • Page 48 Turning Technologies assumes no responsibility for technical, or editorial errors, or omissions that may appear in this document, or for the use of this material. Nor does GTCO CalComp by Turning Technologies make any commitment to update the information contained in this document. This document contains proprietary information which is protected by copyright.
