2. INTRODUCTION
3. VOLTAGE REQUIREMENTS
KL18ma operates safely and without audio discontinuity if the AC voltage stays within either of two operating
windows:
95-125 (voltage selector on 115 V) or 195-250 V (voltage selector on 230 V), at 50 or 60 Hz.
The device is default set to be connected to 230 V AC Power. To use the device on a 115 V AC Power you need,
before connecting it, to move the voltage selector's cover, just loosening the two screws, and to choose the correct
use voltage by the red switch. Be sure that both voltage set on the selector and AC Power have the same value .
Always close the voltage selector's cover before connecting the device to AC Power. Change the label that points
out the correct voltage in use.
USER'S MANUAL
REV. A
The
KL18ma features a 1600 watt 18" drive unit with neodymium magnet structure and suspension
engineered for maximum linear excursion. Its ultra-light reflex cabinet is fitted with two pocket
handles and one 35mm pole mounting point for easy installation with every satellite speaker on it.
Combinig the KL18ma with the middle-high speakers KR200, we obtain a high performance ultra-
slim powered two way system, called KR200S, designed for small to medium wavefront systems, in
both mobile and installed applications.
The KR200S includes two KR200 satellites and 2 KL18ma powered subwoofers.
The KR200S features a line array of 32x2" high efficiency neodymium magnet drivers enclosed in an
ultra-strong chassis, to ensure high resistance and durability in the hardest working conditions.
The KR200S thanks to true line array technologies and powerful DSP system, achieve outstanding
power and coherence throughout the intended coverage allowing a wide dynamic range and a
faithful reproduction of sound.
All the components are
control quality system.
CAUTION
Connecting a 115V system
!
damages to the device and serious risk for users .
designed by K-array R&D department and custom made under K-array
on a 230V AC Power causes heavy
pag. 03
115-230
ENGLISH
