Technical Data - K-array Redline KL18ma User Manual

8. TECHNICAL DATA

Acoustics
Power handling
Max power
Impedance
Operating frequency range
Frequency range
SPL 1W/1mt
Maximum SPL
Cross over
Type
Frequency
Transducers
Low frequency
High frequency (KR200)
Audio Input
Connectors
Wiring
Audio powered Output
Connector
Wiring
Remote control Input
Connectors
Power Input
Connectors
Amplifiers
Type
Subwoofer power
Satellite power output
Protections
Operating range
Max continuos and burst current
Measures
Weight
1. Power handling is measured following AES standard conditions: transducers driven continuously for two hours with a band-limited noise signal having 6 dB of crest factor.
2. Max power is the maximum RMS applicable power for a musical signal, the referement signal is the one proposed by EIAJ standard.
3. Recommended maximum operating frequency range. Response depends on loading conditions and room acoustics.
4. Free field measured with 1/3 octave frequency resolution at 2 mt.
5. Measured@4 mt then scaled@1 mt.
6. Measured with audio source @1 mt.
7. This is the frequency in which the transducers produce the same sound pressure level (measured@2 mt).
8. Amplifier wattage rating is based on the maximum unclipped burst sine wave RMS voltage that the amplifier will produce into the nominal load impedance .
Viale Roma 7/i 50037 San Piero a Sieve (Firenze) Italy - tel +39 055 8487222 fax
USER'S MANUAL
REV. A
AC power
Physical
HP Sound Equipment s.r.l. - www.k-array.com
1
800(sub) + 500(sat) w
1200(sub) + 1200(sat) w
8 (sub) + 8 (sat) W W
30Hz - 19 KHz +/- 3dB (preset relating)
35Hz - 19 KHz +/- 3dB (preset relating)
5
97 dB(sub) 101 dB(sat)
127dB continuos - 133 dB peak
DSP controlled preset relating
150 Hz minimum (preset relating)
1 x 18" Neodymium speakers with 3" voice coil
32 x 2" Neodymium speakers with 0,75" voice coil
male + female parallel 3 poles balanced XLR
Pin1 = ground / Pin2 = hot /
Female Speakon
Pin1+ = CH1+ / Pin1- = CH1- /
1 x female 8 poles RJ45
2 x PowerCon IN/OUT (max out 14 A)
1 modules class D - DSP controlled
8
1000 Watt
8
1000 Watt
Dynamic limiter, over current, over temp, short circuits
Standard 210 - 240 Vac 50Hz (standard)
Optional 100 - 120 Vac 60Hz (optional)
Standard 6A(>10 sec) - 12A (<1 sec)
Optional 10A(>10 sec) - 20A (<1sec)
46.5 x 46.5 x 58.5 cm (KL18ma) 5.5 x 7 x 200 cm (KR200)
20 Kg (KL18ma) 9 Kg (KR200)
Notes for data
pag. 12
2
3
4
6
7
Pin3 = cold
Pin2+ = N.C. /
+39 055 8487238 e-mail: info@k-array.com
Pin2- = N.C.
ENGLISH
