WARNING: Please refer to the System Installation Manual for
information on limitations regarding product use and function and
information on the limitations as to liability of the manufacturer.
Installation Manual
LCD55 O 1Z32-433 NA
version 4.1
DLS-3 v1.3 or higher

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCD55O1Z32-433 and is the answer not in the manual?

Questions and answers

Related Manuals for DSC LCD55O1Z32-433

Summary of Contents for DSC LCD55O1Z32-433

  • Page 1 WARNING: Please refer to the System Installation Manual for information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. Installation Manual LCD55 O 1Z32-433 NA version 4.1 DLS-3 v1.3 or higher...

  • Page 2: Table Of Contents

    Table of Contents Introduction Section 1: Installation Unpacking ......................... 2 Mounting ........................2 Wiring .......................... 2 Applying Power ......................3 Enrolling the Keypad ....................3 Section 2: Keypad Programming Programming the Keypad ..................5 Function Key Options ....................5 Clock Options ......................5 Alarms Displayed While Armed Option ..............

  • Page 3: Introduction

    NOTE: Control panels previous to version 2.3 support 8 wireless zones. NOTE: Only one LCD5501Z32 keypad can be connected per system. If more keypads are required please select other DSC compatible keypads for the system being installed. Specifications and Features •...

  • Page 4: Section 1: Installation

    Installation 1.1 Unpacking The LCD5501Z32-433 package includes the following par The LCD5501Z32-433 package includes the following par The LCD5501Z32-433 package includes the following par The LCD5501Z32-433 package includes the following par The LCD5501Z32-433 package includes the following parts: • One LCD5501Z32-433 keypad •...

  • Page 5: Applying Power

    1.4 Applying Power Once all wiring is complete, apply power to the control panel: 1. Connect the battery leads to the battery. 2. Connect the AC transformer. For more information on control panel power specifications, see the control panel Installation Manual . NOTE: Do not connect the power until all wiring is complete.
  • Page 6 If both modules do not show on the keypad, one of the following conditions may be present: • the keypad is not connected properly to the Keybus • there is a problem with the Keybus wiring run • the keypad does not have enough power 1.6 Downloading This product has an integrated PC5132-433 v4.1 receiver.

  • Page 7: Section 2: Keypad Programming

    Keypad Programming 2.1 Programming the Keypad There are several programming options available for the LCD5501Z32-433 keypad. These are described below. Record all your programming choices in the program- ming worksheets included in this manual. Programming the LCD5501Z32-433 is similar to programming the rest of the system. When you are in the LCD5501Z32-433 programming sections, the keypad will display which options are turned on along the top of the display.

  • Page 8: Alarms Displayed While Armed Option

    2.4 Alarms Displayed While Armed Option You can disable the display of alarms on the keypad when the system is armed. The display of alarms is enabled by default. To disable the display of alarms when the system is armed, turn off section [6], option [5]: 1.
  • Page 9 1. Enter [*][8][Installer’s code] 2. Enter [000] to go to keypad programming 3. Enter section [6]. 4. To turn the options on or off, press [6] or [7]: ON = Door Chime Enabled for Zone Openings OFF = Door Chime Disabled for Zone Openings ON = Door Chime Enabled for Zone Closings OFF = Door Chime Disabled for Zone Closings...

  • Page 10: Section 3: Receiver Programming

    Receiver Programming Enroll & Program Devices This section describes how to enroll and program: • wireless devices using zones (WLS904P, WLS906, WLS907, WLS912, WLS914 and WLS925L) • wireless keys (WLS909, WLS919) For more information on these devices, read the instruction sheet included with each device.

  • Page 11: Enroll & Program Wireless Keys

    E N R O L L & P R O G R A M D E V I C E S 5. The device is now enrolled on the system. Record the serial number and the assigned zone number in the programming worksheets in the back of this manual. 6.

  • Page 12: Identified Wireless Keys

    E N R O L L & P R O G R A M D E V I C E S 1. At a system keypad, enter [ ][8][Installer’s code]. 2. Enter programming section [804]. 3. Enter programming section [59] for keys assigned to partition 1, or [60] for keys assigned to partition 2.

  • Page 13: Enrolling & Programming Handheld Keypads

    E N R O L L & P R O G R A M D E V I C E S 3.5 Deleting Wireless Devices To remove a wireless device from the system, follow the guideline for adding a wireless device.

  • Page 14: Section 4: Other Programming

    Other Programming 4.1 Program Zones and Partitions Now that you have enrolled the wireless devices, you should complete all zone programming on the system. Although the exact programming required varies de- pending on which control panel the LCD5501Z32-433 is connected to, you should check that the following programming areas are completed correctly for each wireless zone: •...

  • Page 15: Rf Jam Detect Zone

    To program the wireless supervisory window: 1. Enter [ ][8][Installer Code] to enter Installer Programming. 2. Enter [804] to enter into Receiver Programming. 3. Enter sections [81]. 4. Enter the time period for the supervisory window (8 to 24 hours). 5.
  • Page 16 To restore the PC5132 programming to the factory default settings, perform the following: 1. Enter [ ][8] [Installer’s Code]. 2. Enter programming section [996]. 3. Enter the Installer’s Code, followed by [996] again. Press [#]. The software for the receiver section will be restored to its factory default settings. 4.

  • Page 17: Section 5: Testing & Mounting

    Testing & Mounting 5.1 Test the placement of the WLS904P, WLS906, WLS907, WLS912, WLS914 and the WLS925L It is very important to test the proposed placement of each wireless device before it is mounted. Following these steps will test the placement of the wireless motion detectors (WLS904P/WLS914), wireless smoke detectors (WLS906), wireless glassbreak detectors (WLS912) and wireless door/window contacts (WLS907/WLS925L), based on the signal strength between the LCD5501Z32-433 and the device.

  • Page 18: Test Wls909 And Wls919 Reception

    & 5.2 Test WLS909 & WLS919 Reception The wireless key (WLS909) cannot be tested using the module placement test described above. To ensure that the LCD5501Z32-433 is receiving transmissions from these devices, conduct the following tests: WLS909/WLS919: Use the function keys to arm and disarm the system at several different points in the installation.

  • Page 19: Section 6: Additional Notes

    Additional Notes 6.1 Trouble Conditions The control panel always watches for possible trouble conditions. If a trouble condition occurs, the keypad “Trouble” light will turn on and the keypad will beep. Press [ ][2] to display the trouble conditions. The following trouble conditions apply to the receiver portion (identified as the PC5132 by the panel) and/or any enrolled devices.

  • Page 20: Section 7: Troubleshooting

    Tro u b l e s h o o t i n g 1. When I enter the 2-digit zone number when adding a wireless device, the keypad gives me a long beep. You cannot enter ESNs unless the LCD5501Z32-433 is properly connected to the Keybus. See sections 1 &...

  • Page 21: Section 8: Programming Worksheets

    Programming Worksheets [000] Keypad Programming 1. Enter [*][8][Installer’s code] 2. Enter [000] to go to keypad programming [0] Keypad Enrollment Valid entries are 01-18; e.g. enter [11] for partition 1, slot 1. Default = 11 1st digit Enter 0 for Global Keypad Enter 1 for Partition 1 Keypad Enter 2 for Partition 2 Keypad 2nd digit...
  • Page 22 P R O G R A M M I N G W O R K S H E E T S [*] Door Chime Sound Programming 1. Enter [*][8][Installer’s code][*] 2. Enter 2-digit zone number [01] - [32], then select door chime sound option [1] - [4]. Repeat for each zone that is to sound a chime.
  • Page 23 P R O G R A M M I N G W O R K S H E E T S [804] Wireless Expansion Programming • 6-digit entry is required. See Section 3.1 “A note on Electronic Serial Numbers” for details on programming 6-digit serial numbers. •...
  • Page 24 P R O G R A M M I N G W O R K S H E E T S Wireless Key Serial Numbers Default = 000000 [41] Key 01 [49] Key 09 l _____ l _____ l _____ l _____ l _____ l _____ l l _____ l _____ l _____ l _____ l _____ l _____ l [42] Key 02 [50] Key 10...
  • Page 25 P R O G R A M M I N G W O R K S H E E T S Default = 00 Default = 00 Default = 00 Default = 00 Default = 00 Partition 1 Wireless Key Options [59] Function Key 1 Function Key 3 l _ ___ l _ ___ l...
  • Page 26 P R O G R A M M I N G W O R K S H E E T S [84] Zone Device Supervision Options (17-24) Zone Device Supervision Options (17-24) Zone Device Supervision Options (17-24) Zone Device Supervision Options (17-24) Zone Device Supervision Options (17-24) Default = ON Option ON...
  • Page 27 P R O G R A M M I N G W O R K S H E E T S Wireless Keys (1-8) Partition Assignments Wireless Keys (1-8) Partition Assignments [91] Wireless Keys (1-8) Partition Assignments Wireless Keys (1-8) Partition Assignments Wireless Keys (1-8) Partition Assignments Default = ON Option ON...

  • Page 28: Appendix A: Guidelines For Locating Smoke Detectors

    Guidelines for Locating Smoke Detectors Experience has shown that all hostile fires in family living units generate smoke to a greater or lesser extent. Experiments using typical fires in family living units indicate that detectable quantities of smoke precede detectable levels of heat in most cases. In existing homes, NFPA Standard 72 requires that a smoke detector be installed outside each sleeping area and on each additional story of the family unit.

  • Page 29: Limited Warranty

    LIMITED WARRANTY Digital Security Controls Ltd. warrants the original purchaser that for a period of twelve months from the date of purchase, the product shall be free of defects in materials and workmanship under normal use. During the warranty period, Digital Security Controls Ltd.

  • Page 30: Power Failure

    WARNING Please Read Carefully Note to Installers Every fire is different in the amount of smoke produced and the rate This warning contains vital information. As the only individual in of burning. Smoke detectors cannot sense all types of fires equally contact with system users, it is your responsibility to bring each item well.
  • Page 32 (2) l’utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif. ©2000 Digital Security Controls Ltd. Toronto, Canada 1-800-387-3630 • www.dsc.com Printed in Canada 29005206 R002...
