Quick Start cont.
Tilt
Grasp both sides of the monitor screen with your
hands and adjust the tilt as desired (Figure TS.1).

Remove Monitor Stand for Mounting

To prepare the monitor for alternate mounting purposes:
1. Remove the back cover and the cable cover
(Figure R.1).
2. Disconnect all cables.
3. Place monitor face down on a non-abrasive surface (Figure R.2).
4. Remove the 4 screws connecting the monitor to the stand and lift off the stand
assembly (Figure R.2). The monitor is now ready for mounting in an alternate
manner.
5. Connect the AC Adapter cord to the back of the monitor marked "DC in"
(Figure R.3).
6. Reverse this process to reattach stand.
NOTE: Use only VESA-compatible alternative mounting method.
When the monitor stand is removed, the USB capabilities
will be disabled.
Please use only the supplied AC Adapter (#A2425S01).
CAUTION
Figure R.2
Non-abrasive surface
78134761.wpc
1
Figure R.1
Figure R.3
6
8
Figure TS.1
2
9/16/99, 4:10 PM
