Controls cont.
AccuColor ® Control System
Five color presets select the desired color setting. If a setting is adjusted, the
name of the setting will change to Custom.
Color Gain (Red, Green, Blue): Increases or decreases Red, Green or
Blue color depending upon which is selected. The change in color will
appear on screen and the direction (increase or decrease) will be shown
by the color bars.
Tools
Language Select: OSM control menus are available in seven
languages.
Position: You can choose where you would like the OSM
OSM
™
control image to appear on your screen. Selecting OSM Location allows
you to manually adjust the position of the OSM control menu left, right,
up or down.
OSM Turn Off: The OSM control menu will stay on as long as it is in
use. In the OSM Turn Off submenu, you can select how long the monitor
waits after the last touch of a button to shut off the OSM control menu.
The preset choices are 10, 20, 30, 60 and 120 seconds.
OSM Lock Out: This control completely locks out access to all OSM
control functions. When attempting to activate OSM controls while in
the Lock Out mode, a screen will appear indicating the OSM controls
are locked out. To activate the OSM Lock Out function, press
PROCEED, then and hold down simultaneously. To de-activate the
OSM Lock Out, press PROCEED, then and hold down simultaneously.
Factory Preset: Selecting Factory Preset allows you to reset all OSM
control settings back to the factory settings. The RESET button will need
to be held down for several seconds to take effect. Individual settings
can be reset by highlighting the control to be reset and pressing the
RESET button.
Resolution Notifier: This optimal resolution is 1280 x 1024. If ON
is selected, a message will appear on the screen after 2 minutes,
notifying you that the resolution is not at 1280 x 1024.
Information
Shows the selected video input and USB upstream.
Display Mode: Provides information about the current resolution display
and technical data including the preset timing being used and the
horizontal and vertical frequencies.
9
