Specifications
Product Specifications(LCD3210)
LCD Module
Pixel Pitch
Resolution
Color
Brightness
Contrast ratio
Viewing Angle
Design View Distance
Frequency
Horizontal
Vertical
Pixel Clock
Viewable Size
Input Signal PC Input
Video
Sync
Input terminal
VIDEO Input
AUDIO Input
RS232C
Output
PC
signal
VIDEO
AUDIO
SPEAKER OUTPUT
Power Supply
Operational Temperature
Environment
Humidity
Storage Temperature
Environment
Humidity
Dimension
Net
Gross
Weight
Net
Gross
VESA compatible arm
mounting interface
Complied Regulatory and
Guidelines
Power Management
Plug & Play
Resolutions Supported
Accessories
NOTE: Technical specifications are subject to change without notice.
Denotes an AV unit function.
AV
All AV functions are enabled when the AV unit is installed.
Analog Input
(32" / 80 cm diagonal)
0.511mm
1366 x 768 dots
Over 16 million colors (depending on video card used)
500cd/m2 (Typ.)
600 : 1
Up 88 / Down 88 / Left 88 / Right 88 (typ) @ CR >10
875mm
15.625/15.734kHz , 31.5kHz - 91.1kHz
50Hz, 60Hz to 85Hz
25.0MHz - 162.0MHz
392.3 x 697.7mm
Analog RGB 0.7V p-p
Input Impedance 75 Ohm
Composite sync on Green Video
: 0.3Vp-p Nega (video 0.7Vp-p Positive)
Separate: TTL level (Positive/Negative), Input
Impedance 2.2k Ohm(RGB3:2.2k ohm/75 ohm selectable)
BNC (R,G,B,H,V) 15pin Mini D-sub
Composite 1.0V p-p Input Impedance 75 Ohm BNC and RCA-INPUT
Y/C Y:0.7V p-p C:0.283V p-p Input Impedance 75 Ohm S-TERMINAL-INPUT
Component 1.0/0.7V p-p Input Impedance 75 Ohm BNC-INPUT
RCA PIN-JACK L/R 2INPUT, STEREO Mini Jack 1INPUT
9 Pin Mini D-sub
In
Analog RGB Video: 0.7V p-p with 75 ohm terminated
Video
Seperate HV sync: TTL level (Posi/Nega) with 2.2k ohm terminated
Sync
Mini D0sub 15pin
Connector
BNC 1 Output, Composite 1.0V p-p with 75 ohm ternminated
RCA PIN-JACK L/R: 1 Output, 0.15Vrms with 1k ohm terminated
External Speaker Jack 7W + 7W
1.4 - 0.6A @ 100-240VAC, 50/60Hz
5 - 40 deg C
20 - 80% (without condensation)
-20 - 60 deg C
10 - 90% (without condensation) / 90% - 3.5% x (temp - 40 deg C) regarding over 40 deg C
789.0 (W) x 479.0 (H ) x 140.0 (D) mm (without Stand), 789.0 (W) x 510.3 (H) x 200 (D) mm (with Stand)
944 (W) x 652(H) x 312 (D) mm
34.2 lbs / 15.5kg (without Stand)
46.3 lbs / 21.0kg
3 x 200mm x 200mm (8 Holes)
2 x 200mm x 200mm (6 Holes)
UL 60950-1/CSA C22.2 No.60950-1/ TUV-GS/EN60950-1
FCC-B/DOC-B/EN55022-A/EN55024/EN61000-3-2/EN61000-3-3/CE
VESA DPM
VESA DDC2B, DDC/CI
640 x 480 at 60Hz to 85Hz
800 x 600 at 50Hz, 60Hz to 85Hz
1024 x 768 at 50Hz, 60Hz to 85Hz
1280 x 768 at 50Hz, 60Hz to 85Hz
1360 x 768 at 50Hz, 60Hz* to 85Hz
1280 x 1024 at 60Hz to 85Hz
1600 x 1200 at 60Hz .....Maximum Resolution
*Recomended Resolution
NTSC / PAL / SECAM / 4.43NTSC / PAL60
Compoment: 480i, 480p, 720p, 1080i,
User's manual, Power Cord, Video Signal Cable, Remote Control, AA Battery x 2, Clamper x 3,
Screw x 4, CD-ROM, Stand x 2, Thumbscrew for stand x 2, Main switch cover x 1,
Ferrite Core x 2, Band x 2, Speaker plug x 1set
Digital Input
31.5kHz - 91.1kHz
TMDS
DVI-D (Digital)
36.4 lbs / 16.5kg (with Stand)
AV
AV
