Specifi Cations - C431 - NEC MultiSync C431 User Manual

Specifi cations - C431
Product Specifi cations
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
DisplayPort DisplayPort Connector Digital RGB
VGA 15pin Mini D-sub
2
(RGB)*
HDMI HDMI Connector
VGA 15pin Mini D-sub
2
(YPbPr)*
VIDEO* 2 RCA port
AUDIO
AUDIO Stereo Mini Jack
Input
HDMI Connector
DisplayPort Connector Digital Audio
AUDIO Stereo Mini Jack
Output
Speaker Output
Control
SD card Slot
USB Port
Power Supply
Power Consumption
Operational Environment
Storage Environment
Dimension
Weight
VESA compatible mounting interface
Power Management
NOTE: Technical specifi cations are subject to change without notice.
*1: Compressed image.
*2: Common terminal.
43"/107.95 cm diagonal
Pixel Pitch: 0.49 mm
Resolution: 1920 x 1080
Color: Over 1073 million colors (depending on display card used)
Brightness: 400 cd/m 2 (Max.) @25°C
Contrast Ratio: 4000:1
Viewing Angle: 89° (typ) @ CR>10
Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz
Vertical: 50.0 - 85.0 Hz (Analog Input)
24.0 - 85.0 Hz (Digital Input)
Analog: 13.5 MHz, 25.0 MHz - 165.0 MHz
Digital: 25.0 MHz - 165.0 MHz
940.90 x 529.25 mm
The DisplayPort input complies with Standard V1.1a, applicable to HDCP
SVGA60, XGA60, WXGA60, SXGA60, UXGA60, WUXGA60*
1080i, 720p@50Hz/60Hz
Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Digital YUV HDMI
Digital RGB SVGA60, XGA60, WXGA60, SXGA60, UXGA60, WUXGA60*
1080i, 720p@50Hz/60Hz
Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz,
480i@60Hz
Composite 1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
Analog Audio Stereo L/R 0.5 Vrms x 2
Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
PCM 32, 44.1, 48 KHz (16/20/24bit)
Analog Audio Stereo L/R 0.5 Vrms
Internal Speaker 10 W + 10 W (Stereo)
RS-232C In: 9 Pin D-sub
LAN: RJ-45 10 BASE-T/100 BASE-TX x1
Stereo Mini Jack 3.5 mm Ø
Remote IN:
Stereo Mini Jack 3.5 mm Ø
Remote OUT:
Port: microSD card. Up to 32GB microSDHC is supported.
USB (2A): Media Player/Firmware update/Power supply port 5V/2A (max.)
1.35 - 0.55 A @ 100-240V AC, 50/60Hz
Normal operation: Approx. 50 W
Temperature: 0 - 40°C / 32 - 104°F
Humidity: 20 - 80% (without condensation)
Altitude: 0 - 3000 m (Brightness may decrease with altitude)
Temperature: -20 - 60°C / -4 - 140°F
Humidity: 10 - 90% (without condensation) / 90% - 3.5% x (Temp - 40°C) regarding over 40°C
970.7 (W) x 558.9 (H) x 45.0 (D) mm/38.2 (W) x 22.0 (H) x 1.8 (D) inches (w/o Deco Dimension)
12.5 kg (27.6 lbs)
300 mm x 300 mm (M6, 4 Holes)
VESA DPM
English-54
1
, 1920x1080 (60 Hz), 1080p,
1 1
, WUXGA60* , 1920X1080 (60Hz)
1
, 1920x1080 (60 Hz), 1080p,
