Connections
Before connecting external equipment to LCD:
*
First turn off the power to all of the equipment associated with the LCD as well as that of the equipment to be connected.
*
For questions regarding external equipment please refer to the user's manual supplied with that equipment.
LCD monitor
AV
AV
VCR
Attaching the Ferrite Core
Attach the Ferrite Core to PC Audio Cable.
Use of the cable without mounting the ferrite core may result in the
occurrence of noise.
• For PC Audio Cable
Open the ferrite core and clamp
1
it on the PC Audio cable.
Ferrite Core
Wiring Diagram
Personal computer
AV
AV
Equipment with
digital Interface
Mounting Position of Ferrite Core
AV
Attach the Ferrite Core to the both ends of PC Audio Cable.
Close the ferrite core.
2
To AUDIO 1 of monitor
English-12
DVD player
Personal computer
LCD monitor (second monitor)
Ferrite Core
Band
AV
Ferrite Core
To connector of PC
Band
