  • Page 1

    User’s Manual MultiSync LCD3215 MultiSync LCD4215...

  • Page 2: Table Of Contents

    ADVANCED OPTION ... English-23 Controlling the LCD monitor via RS-232C Remote Control ... English-26 Features ... English-27 Troubleshooting ... English-28 Specifications - LCD3215 ... English-29 Specifications - LCD4215 ... English-30 Pin Assignment ... English-31 Manufacturer’s Recycling and Energy Information ... English-32...

  • Page 3: Important Information

    Voltage 120* *When operating the MultiSync LCD3215/MultiSync LCD4215 monitor with its AC 125-240V power supply, use a power supply cord that matches the power supply voltage of the AC power outlet being used. NOTE: This product can only be serviced in the country where it was purchased.

  • Page 4: Canadian Department Of Communications Compliance Statement

    C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No. 60950-1. FCC Information 1. Use the attached specified cables with the MultiSync LCD3215 (L327HP)/MultiSync LCD4215 (L427HQ) color monitor so as not to interfere with radio and television reception.

  • Page 5: Safety Precautions, Maintenance & Recommended Use

    Safety Precautions, Maintenance & Recommended Use FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE MULTI-FUNCTION MONITOR: • DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. Refer all servicing to qualified service personnel.

  • Page 6: Contents

    Contents Your new MultiSync monitor box* should contain the following: • LCD monitor • Power Cord* • Video Signal Cable • Setup Manual • Wireless Remote Control and AAA Batteries • Main switch cover Video Signal Cable (Mini D-SUB 15 pin to Mini D-SUB 15 pin) Power Cord* CD-ROM...

  • Page 7: Installation

    Please note the following when mounting on wall or ceiling • When using mounting accessories other than those that are NEC approved, they must comply with the VESA- compatible (FDMlv1) mounting method. • NEC strongly recommends Unit using size M6 screws (9 mm + thickness of bracket in length).

  • Page 8: Attaching Mounting Accessories

    The protective sheet was wrapped around the LCD in the original packaging. Make sure there is nothing on the table that can damage the monitor. When using mounting accessories other than NEC compliant and approved, they must comply with the VESA- compatible mounting method.

  • Page 9: Parts Name And Functions

    Parts Name and Functions Control Panel POWER button ( ) Switches the power on/off. See also page 18. MUTE button Switches the audio mute ON/OFF. INPUT button Acts as SET button within OSD menu. Toggle switches between [RGB1], [RGB2], [RGB3], [DVD/HD], [VIDEO(S)] or [VIDEO].

  • Page 10: Terminal Panel

    PC in order to control RS-232C functions. EXTERNAL SPEAKER TERMINAL To output the audio signal from AUDIO 1, 2, 3. Note: This speaker terminal is for optional speaker. SP-3215 for MultiSync LCD3215, SP4020-4620 for MultiSync LCD4215. Kensington Lock (LCD4215 only) For security and theft prevention.

  • Page 11: Wireless Remote Control

    Wireless Remote Control POWER button Switches the power on/off. INPUT button Selects input signal, [RGB1], [RGB2], [RGB3], [DVD/HD], [VIDEO(S)] or [VIDEO]. AUDIO INPUT button Selects audio input source [AUDIO:1], [AUDIO:2], [AUDIO:3]. SIZE button Selects picture size, [FULL], [NORMAL], [CUSTOM], [DYNAMIC] and [REAL]. See page 19. PICTURE MODE button Selects picture mode, [HIGHBRIGHT], [STANDARD], [sRGB], [CINEMA].

  • Page 12: Operating Range For The Remote Control

    Operating Range for the Remote Control Point the top of the remote control toward the LCD monitor’s remote sensor during button operation. Use the remote control within a distance of about 7 m (23 ft.) from the front of the LCD monitor’s remote control sensor or at a horizontal and vertical angle of within 30°...

  • Page 13: Setup

    C. Replace the cover. CAUTION: Incorrect usage of batteries can result in leaks or bursting. NEC recommends the following battery use: • Place “AAA” size batteries matching the (+) and (-) signs on each battery to the (+) and (-) signs of the battery compartment.

  • Page 14: External Equipment

    5. Switch on the power of all the attached external equipment When connected with a computer, switch on the power of the computer first. 6. Operate the attached external equipment Display the signal from the desired input source. 7. Adjust the sound Make volume adjustments when required.

  • Page 15: Connections

    Connections Before making connections: First turn off the power of all the attached equipment and make connections. Refer to the user manual included with each separate piece of equipment. Wiring Diagram BNC-to-RCA adapter BNC x 3 DVD player To DVD Component To audio output video output To audio output...

  • Page 16: Connecting A Personal Computer

    Connecting a Personal Computer Connecting your computer to your LCD monitor will enable you to display your computer’s screen image. Some video cards and a pixel clock over 165MHz may not display an image correctly. Your LCD monitor displays proper image by adjusting the factory preset timing signal automatically. <Factory preset signal timing>...

  • Page 17: Connecting With Digital Interface Equipment

    Connecting with Digital Interface Equipment Connections can be made with equipment that is equipped with a digital interface that complies with the DVI (Digital Visual Interface) standard. Connect the LCD Monitor to a Computer with a Digital Output • The RGB1 connector also accepts a DVI-D cable. •...

  • Page 18: Connecting A Dvd Player With Component Out

    Connecting a DVD Player with component out Connecting your DVD player to your LCD monitor will enable you to display DVD video. Refer to your DVD player user’s manual for more information. Connect the LCD Monitor to a DVD Player •...

  • Page 19: Connecting To A Stereo Amplifier

    Connecting to a Stereo Amplifier You can connect your stereo amplifier to your LCD monitor. Refer to your amplifier owner’s manual for more information. Connect the LCD Monitor to a Stereo Amplifier • Turn on the LCD monitor and the amplifier only after all connections have been made. •...

  • Page 20: Basic Operation

    Basic Operation Power ON and OFF Modes The LCD monitor power indicator will turn green while powered on and will turn red while powered off. NOTE: The Main Power Switch must be in the ON position in order to power up the monitor using the remote control or the Power Button on the front of the LCD.

  • Page 21: Power Indicator

    Power Indicator Status Power ON Green Power OFF Power Standby when Red On “SCHEDULE” is enabled Green Blinking Power Standby Red, Green Diagnosis (Detecting failure) Red Blinking * See troubleshooting on page 28 Using Power Management The LCD monitor follows the VESA approved DPM Power Management function.

  • Page 22: Osd (on-screen-display) Controls

    OSD (On-Screen-Display) Controls Remote Control Press MENU button to Press “+”, “-” button to open Main menu. select Sub menu, and press Up, Down button to enter Sub menu. Control Panel Press EXIT button to open Main menu and press “+”, “-” button to select Sub menu.

  • Page 23: Picture

    Setting PICTURE BRIGHTNESS Adjusts the overall image and background brightness. CONTRAST Adjusts the image brightness in relation to the input signal. NOTE: sRGB picture mode is standard and cannot be changed. SHARPNESS Adjusts the crispness of the image. BLACK LEVEL Adjusts the image brightness in relation to the background.

  • Page 24: Audio

    CUSTOM ZOOM “CUSTOM ZOOM” will be selected when you select “CUSTOM” on the screen “ZOOM” mode. ZOOM Expands the horizontal and the vertical size simultaneously. H ZOOM Expands the horizontal size only. V ZOOM Expands the vertical size only. H POS Moves to the right with + button.

  • Page 25: Multi Display

    MULTI DISPLAY IR CONTROL Selects the infrared wireless remote controller mode. The item in this menu will become effective by pressing “SET” button on the selected item. NORMAL The monitor will be controlled normally by wireless remote controller. LOCK Disables the monitor control by infrared wireless remote controller. Keep pressing “DISPLAY”...

  • Page 26: Advanced Option

    ADVANCED OPTION DVI MODE Selects the kind of DVI-D equipment which is connected RGB1. Selects “DVI-PC” when PC or other computer equipment is connected. INPUT RGB1 only Selects “DVI-HD” when DVD player, which has DVI-D output, is connected. SCAN CONVERSION Selects IP (Interlace to Progressive) converter function.

  • Page 27

    As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying moving images and using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.

  • Page 28: Controlling The Lcd Monitor Via Rs-232c Remote Control

    Controlling the LCD monitor via RS-232C Remote Control This LCD monitor can be controlled by connecting a personal computer with a RS-232C terminal. Functions that can be controlled by a personal computer are: • Power ON or OFF • Switching between input signals Connection LCD Monitor + PC PC (Out)

  • Page 29: Features

    Allows for the monitor to be mounted on a wall or an arm using any third party compliant device. NEC recommends using mounting interface that comply with TÜV-GS and/or UL1678 standard in North America.

  • Page 30: Troubleshooting

    NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying moving images and using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.

  • Page 31: Specifications - Lcd3215

    Specifications - LCD3215 Product Specifications LCD Module Pixel Pitch: Resolution: Brightness: Contrast Ratio: Viewing Angle: Design View Distance: Frequency Horizontal: Pixel Clock Viewable Size Input Signal RGB1 DVI-D 24pin Digital RGB RGB2 15pin Mini D-sub Analog RGB Sync RGB3 BNC (R,G,B,H,V)

  • Page 32: Specifications - Lcd4215

    Specifications - LCD4215 Product Specifications LCD Module Design View Distance: Frequency Pixel Clock Viewable Size Input Signal RGB1 DVI-D 24pin Digital RGB RGB2 15pin Mini D-sub Analog RGB Sync RGB3 BNC (R,G,B,H,V) Analog RGB Sync DVD/HD BNC (Y, Cb/Pb, Cr/Pr) Component VIDEO(S) Mini DIN 4 pin...

  • Page 33: Pin Assignment

    Pin Assignment 1) Analog RGB input (MiniDsub15p): VGA Pin No Name Video Signal Red Video Signal Green Video Signal Blue DDC-GND Red-GND Green-GND Blue-GND +5V (DDC) SYNC-GND DDC-SDA H-SYNC V-SYNC DDC-SCL 2) VIDEO(S) input: VIDEO Pin No Name Y (Luminance) C (Chroma) 3) Digital RGB input (DVI-D): DVI Pin - Assignment of DVI connector:...

  • Page 34: Manufacturer's Recycling And Energy Information

    Manufacturer’s Recycling and Energy Information NEC DISPLAY SOLUTIONS is strongly committed to environmental protection and sees recycling as one of the company’s top priorities in trying to minimize the burden placed on the environment. We are engaged in developing environmentally- friendly products, and always strive to help define and comply with the latest independent standards from agencies such as ISO (International Organisation for Standardization) and TCO (Swedish Trades Union).
